Schneider Electric Servo Drive 200W, 1 and 3 Phase, 2.4A, Encoder Feedback, Motion Function LXM28AU02M3X

Schneider Electric LXM28AU02M3X is a high-performance servo drive designed for precise motion control in industrial applications. Operating at 220V with a power output of 200W, it supports both single and three-phase power supplies and provides an output current rating of 2.4A. This servo drive incorporates encoder feedback and a range of motion functions, ensuring accurate positioning and speed control.

The device features EMC filtering and integrated communication interfaces including CANopen and CAN motion, accessible via RJ45 connectors, facilitating smooth integration into automation systems. Its spring terminal connection enhances installation convenience while maintaining electrical isolation between power and control circuits.

The Lexium 28 series, to which this model belongs, is engineered for compact machine applications and is optimized for use with BCH2 servo motors. Its IP20 protection rating ensures suitability for controlled industrial environments, withstanding operating temperatures from 0°C to 55°C. The compact physical dimensions allow space-efficient system design.

The servo drive supports advanced functionality such as auto-tuning, status monitoring, and multiple control modes including relative or absolute positioning, velocity, and torque control. This versatility makes it ideal for precise applications like printing, packaging, winding, unwinding, and material handling.

Weighing only 1 kg, the LXM28AU02M3X is part of the broader Lexium 28 range that delivers reliable, compact, and efficient servo drive solutions, compliant with relevant standards such as CSA and EN/IEC 61800-5-1.

Features encoder feedback and motion control functions for precise operation. Compatible with BCH2 servo motors for compact machine applications. Equipped with EMC filter and integrated CANopen and CAN motion interfaces.

Provides multiple control modes including position, speed, and torque control. IP20 rated with operational temperature range from 0°C to 55°C. Compact dimensions of 150mm (L) x 55mm (W) x 146mm (D) and lightweight at 1 kg.

Suitable for industrial, manufacturing, automation, and material handling use cases, the Schneider Electric LXM28AU02M3X offers a robust and compact solution for precise servo motor control. Explore more Servo Drives and Automation products on EnvMart for your application needs.
