STMicroelectronics Temperature & Humidity Sensor Digital Output, Surface Mount, ±0.5°C (±3.5 %) Accuracy EMC1843T

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Temperature & Humidity Sensor Digital Output, Surface Mount, ±0.5°C (±3.5 %) Accuracy EMC1843T

Name: STMicroelectronics Temperature & Humidity Sensor Digital Output, Surface Mount, ±0.5°C (±3.5 %) Accuracy EMC1843T
Brand: STMicroelectronics
SKU: 138827
Price: 5.51 USD
Availability: InStock



Category Temperature & Humidity Sensor Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Accuracy	±0.5°C (±3.5 %)
Temperature Accuracy	± 0.5 °C 15 to +40 °C
Humidity accuracy	± 3.5% rH, 20 to +80% rH
Brand	STMicroelectronics
Height	900μm
Length	2mm
Model	EMC1843T
RH Range	0 to 100 %
Width	2mm
Mount Type	Surface
Output type	Digital
Series	EMC1843T
Maximum Operating Temperature	120°C
Package Type	HLGA
Sub Type	Temperature & Humidity Sensor
Minimum Operating Temperature	-40°C
Interface Type	Analogue
Standards/Approvals	RoHS
Pin Count	6
Maximum Supply Voltage	3.6V
Minimum Supply Voltage	1.7V
High rH sensitivity	0.004% rH/LSB

Key Features

Compact 2x2x0.9 mm HLGA surface mount package for space-saving PCB integration.
Digital output via SPI and I2C interfaces for flexible communication.
High humidity sensitivity of 0.004% rH/LSB ensuring precise monitoring.
Wide relative humidity range of 0 to 100% with ±3.5% rH accuracy from 20 to +80% rH.
Temperature accuracy of ±0.5°C between 15 to +40°C supports reliable environment sensing.
Operates over a broad temperature range from -40°C up to +120°C for versatile applications.
Low power consumption of 2 μA at 1 Hz output data rate ideal for battery-powered devices.
Selectable output data rates from 1 Hz to 12.5 Hz to balance performance and power.

Product Description

STMicroelectronics EMC1843T Temperature & Humidity Sensor is a highly compact, surface mount device designed for precise and reliable measurement of relative humidity and temperature. It integrates a polymer dielectric planar capacitor sensing element with a mixed-signal ASIC to provide accurate measurements with digital serial outputs via SPI and I²C interfaces. The device is housed in a small HLGA package measuring 2 mm by 2 mm by 0.9 mm, making it suitable for space-constrained designs.

This sensor guarantees operation across an extended temperature range from -40°C to +120°C, ensuring robustness in demanding industrial, commercial, and consumer applications. It offers high sensitivity with a humidity resolution of 0.004% rH/LSB and excellent accuracy, delivering ±3.5% rH within typical humidity conditions and ±0.5°C temperature accuracy within a common operating range of 15 to +40°C. Its low power consumption of 2 μA at a 1 Hz output data rate makes it ideal for battery-operated and portable devices.

Designed for diverse applications, the EMC1843T sensor supports air conditioning units, heating, ventilation, humidifiers, refrigerators, wearable electronics, smart home solutions, industrial automation, respiratory equipment, and asset tracking systems. Its wide supply voltage tolerance from 1.7 V to 3.6 V enhances system compatibility.

Key features include selectable output data rates from 1 Hz to 12.5 Hz, advanced calibration factory programmed, and a six-pin surface mount design for easy PCB integration. The sensor complies with RoHS standards, emphasizing its suitability for modern electronics manufacturing.

Compact size: 2 x 2 x 0.9 mm HLGA package. Digital output via SPI and I²C interfaces. Humidity accuracy ±3.5% rH and temperature accuracy ±0.5°C. Operating temperature range: -40°C to +120°C. Low power consumption: 2 μA typical at 1 Hz ODR.

Supply voltage: 1.7 V to 3.6 V. Applications include HVAC, wearable devices, and industrial automation.

This sensor's combination of size, power efficiency, accuracy, and broad operating conditions make it a reliable choice for instrument designers in industrial, laboratory, commercial, and consumer electronics fields. Explore other sensors and semiconductor components from STMicroelectronics on EnvMart for comprehensive system design.
