HARTING Unmanaged 16 Port Ethernet Switch 100 Mbps Network Speed 24-48V DC DIN-Rail Mount 24030160010

HARTING 24030160010 unmanaged Ethernet switch features 16 RJ-45 ports supporting 100 Mbps Fast Ethernet connections, designed primarily for industrial networking environments. This switch is engineered for DIN-rail installation inside control cabinets, enabling quick and efficient network expansions.

The device offers a wide operating voltage range from 9 volts DC up to 60 volts DC, with built-in surge and reverse-polarity protection to ensure reliable operation in fluctuating power conditions. It operates over an industrial temperature range from -40 °C up to +70 °C, suitable for harsh factory or outdoor conditions including coastal or industrial sites.

Ports automatically negotiate link speed and polarity, and feature MDI/MDI-X auto switching for seamless cable connection without configuration. LED indicators display status for power, link activity, and speed to simplify troubleshooting and monitoring in automation and transport control systems.

Conforming to prominent international standards such as CE, CSA, FCC, and UL, this switch is robust and compliant for electromagnetic compatibility and safety. Energy-Efficient Ethernet technologies reduce power consumption while maintaining full throughput with its non-blocking store-and-forward switching architecture.

This product is ideal for expanding machine-side networks in factory automation, control cabinet networking within renewable wind and solar plants, and on-board Ethernet distribution for shipbuilding and transportation industries. Power is delivered via a 3-pole pluggable screw connector supporting common industrial voltage levels and safety requirements.

Offers 16 RJ-45 ports supporting 10/100 Mbps connections for versatile networking. Unmanaged switch with plug-and-play installation ideal for factory automation and transport. Supports wide input voltage range from 9 V DC to 60 V DC with surge and reverse-polarity protection.

Designed for DIN-rail mounting in industrial control cabinets, saving space. Operating temperature range from -40 °C to +70 °C allows use in harsh environments. LED indicators provide clear status of power, link/activity, and network speed.

Complies with CE, CSA, FCC, and UL standards, ensuring electromagnetic and safety conformity. Energy-efficient design reduces operational power consumption in industrial settings. Suitable for machine-side network expansion, on-board Ethernet distribution, and renewable energy plants.

Power supplied via 3-pole pluggable connector with overcurrent protection and SELV compliance. Explore more Network Switches from leading brands at EnvMart for reliable industrial and commercial networking solutions.
