SMC Brass Pneumatic Male Elbow Fitting KQ2 Series 1/8 in NPT Thread, 0.1875 in Push-in Tube, 45° Angle KQ2L05-34AS
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | SMC |
| Material | Brass |
| Maximum Operating Pressure | 1 MPa, 3 MPa |
| Model | KQ2L05-34AS |
| Connection Type | Threaded |
| Finish | Electroless Nickel Plated |
| Series | KQ2 |
| Maximum Operating Temperature | 60°C |
| Angle | 45° |
| Standards/Approvals | RoHS |
| Connection Size A | NPT 1/8 Male |
| Connection Thread Standard | NPT |
| Connection Thread Size | 1/8 in NPT |
| Connection Gender | Male |
| Tube Connection Type | Push-in |
| Tube Connection Size | 0.1875in |
Key Features
- Constructed from durable brass with electroless nickel plating for corrosion resistance.
- Compatible with NPT 1/8 male threaded connections.
- Push-in tube connection allows quick and easy installation.
- Compact elbow design allows use in confined spaces.
- Operates reliably up to maximum pressures of 1 MPa to 3 MPa.
- Suitable for temperatures up to 60°C.
- Complies with RoHS standards ensuring environmental safety.
- Manufactured in Japan ensuring high quality and precision.
Product Description
SMC KQ2L05-34AS is a brass male elbow pneumatic fitting from the KQ2 Series designed for use with 1/8 inch NPT threads and 0.1875 inch push-in tubes at a 45-degree angle. This fitting is electroless nickel plated to enhance corrosion resistance, making it suitable for demanding industrial applications.
The compact elbow design is ideal for installations within confined spaces, providing ease of connection to female threaded ports at right angles. The push-in tube connection mechanism reduces insertion and removal forces, facilitating quicker maintenance and assembly.
The fitting operates reliably within a maximum pressure range of 1 MPa to 3 MPa and can withstand operating temperatures up to 60°C, making it appropriate for various pneumatic systems in industrial, manufacturing, and fluid power settings.
Constructed of high-quality brass and manufactured in Japan, this fitting complies with RoHS environmental standards. It is designed for use as a threaded-to-tube adaptor in pneumatic tool and automation setups requiring male elbow connections.
Durable brass construction with corrosion-resistant electroless nickel plating. Threaded 1/8 inch NPT male connection compatible with standard pneumatic ports. Push-in tube connection size of 0.1875 inch for secure and easy tubing connection.
Compact 45-degree elbow design for use in limited space applications. Maximum operating pressure range from vacuum conditions to 1 MPa, with a peak up to 3 MPa. Supports maximum operating temperature of 60°C. RoHS certified for environmentally safe material usage.
Manufactured in Japan ensuring precision engineering standards.
This pneumatic fitting is suitable for use across industrial machinery, automation systems, HVAC equipment, and pneumatic distribution lines where robust and compact male elbow fittings are required. It offers reliable sealing and ease of installation in fluid power and tool applications.
Explore more Pneumatic Fittings and pneumatic accessories through EnvMart for comprehensive solutions supporting your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The fitting operates reliably within a maximum pressure range of 1 MPa to 3 MPa.
It features a threaded connection type with a 1/8 inch NPT male thread.
This model is constructed from brass and features an electroless nickel plating for corrosion resistance.
The tube connection size is 0.1875 inches, designed for push-in connections.
It can withstand maximum operating temperatures of up to 60°C.
The fitting has a compact 45-degree elbow design, suitable for confined spaces.
It complies with RoHS standards, ensuring environmentally safe material usage.
This model is manufactured in Japan, ensuring high quality and precision.
It is suitable for use in industrial machinery, automation systems, HVAC equipment, and pneumatic distribution lines.
The push-in tube connection allows for quick and easy installation, reducing insertion and removal forces for maintenance.
This fitting is part of the KQ2 Series, which includes various pneumatic fittings.
The connection thread is male, specifically designed for 1/8 inch NPT connections.
