Molex Mega-Fit Series Right Angle Through Hole PCB Header, 10 Contacts, 5.7 mm Pitch, 2 Row, Shrouded 172064-0010

Molex 172064-0010 Mega-Fit Series Right Angle Through Hole PCB Header is engineered for high current density and compact PCB assembly applications. It features a 10-contact, 2-row configuration with a 5.7 mm pitch, ideal for power connectors requiring up to 23 A per circuit.

The housing is made from a high temperature thermoplastic material with a UL 94 V-0 flammability rating and Glow-Wire Compliance, ensuring robust thermal and electrical safety. The shrouded design offers protection and secures mating connectors effectively.

Contacts are constructed from copper alloy with gold plating to provide excellent conductivity and corrosion resistance, ensuring long-term durability. This PCB header has a right-angle orientation that facilitates flexible PCB layout designs and space-saving configurations.

The terminals are fully isolated, providing protection during handling and mating, and the positive locking mechanism guarantees secure connections with an audible click upon full insertion into mating receptacles.

With operating temperatures ranging from -40°C to 120°C and a voltage rating of 600 V, this connector suits demanding industrial, electronic, and power distribution applications. Typical use cases include industrial electronics assembly, power supply modules, and high current interconnect systems in manufacturing and commercial equipment.

This PCB header features a 2-row, shrouded design ensuring secure wire-to-board connections. The header supports a current rating of 23 A per contact for reliable power delivery. Constructed with high temperature thermoplastic housing material rated UL 94 V-0 for enhanced safety.

Gold-plated copper alloy contacts ensure superior conductivity and durability. Solder termination type and male contact gender enable effective through-hole mounting. Operating temperature ranges from -40°C to 120°C for versatile environmental conditions.

The right-angle orientation and 5.7 mm row pitch improve PCB layout flexibility. Includes positive locking feature for audible click mating to receptacles. Explore a variety of Molex connectors and related PCB header solutions on EnvMart for reliable electronic components and connectors.
