EA Elektro-Automatik Digital Bench Power Supply, 1-Output, 0 V to 42 V, 160 W, 10 A Max EA-PS 2042-10B

Free Delivery in India | Lowest Global Shipping Charges

EA Elektro-Automatik Digital Bench Power Supply, 1-Output, 0 V to 42 V, 160 W, 10 A Max EA-PS 2042-10B

Name: EA Elektro-Automatik Digital Bench Power Supply, 1-Output, 0 V to 42 V, 160 W, 10 A Max EA-PS 2042-10B
Brand: EA Elektro-Automatik
SKU: 128155



Category Bench Power Supplies Brand EA Elektro-Automatik Condition New

Specifications

Country of Origin	China
Brand	EA Elektro-Automatik
Power	160W
Height	82mm
Model	EA-PS 2042-10B
Depth	240mm
Width	174mm
Output type	Digital
Maximum Operating Temperature	50°C
Minimum Operating Temperature	0°C
Plug Type	IEC 320
Number of outputs	1
Maximum Output Current	10A
Standards/Approvals	RoHS
Maximum Output Voltage	42V
Maximum Supply Voltage	264V ac
Minimum Supply Voltage	90V
Digital/Analogue	Digital
Supported Number of Displays	1
Minimum Output Voltage	0V
Minimum Output Current	0A

Key Features

Microprocessor controlled with USB programmability for precision output adjustment.
Features a fully flexible auto-ranging output for voltage or current within rated limits.
Equipped with digital encoders and a full 4-digit LCD display for voltage, current, and function status.
Protected against overcurrent (OCP), overvoltage (OVP), and over-temperature (OTP) for safe operation.
Natural convection cooling and operating temperature range from 0°C to 50°C ensure reliable performance.
Compact and attractive desk-top housing measuring 174 mm width, 240 mm depth, and 82 mm height.
IEC 320 plug type supports supply voltages from 90 V to 264 V AC at 45-65 Hz frequency.
Ideal for educational, industrial, laboratory, manufacturing, and workshop applications.

Product Description

EA Elektro-Automatik EA-PS 2042-10B is a digital bench power supply with a single output channel delivering a voltage range from 0 V to 42 V, maximum current of 10 A, and power rating of 160 W. This laboratory-grade unit is microprocessor controlled and USB-programmable, offering a fully flexible auto-ranging output to suit precise voltage or current demands within its rated specifications.

The power supply is equipped with digital encoders for accurate voltage and current setting and features a full 4-digit LCD segment display. Various function statuses such as output pre-set, lock, and standby are displayed for user convenience. The mini USB port allows computer control for advanced applications.

Designed with natural convection cooling, the unit operates efficiently between 0°C and 50°C ambient temperatures. Safety features include protections against overcurrent (OCP), DC over-voltage (OVP), and over-temperature (OTP), ensuring reliable and safe operation across diverse working environments.

With an IEC 320 plug and voltage supply range from 90 V to 264 V AC at operating frequencies of 45 Hz to 65 Hz, this device supports a wide range of power conditions. Its compact form factor with dimensions 174 mm width, 240 mm depth, and 82 mm height makes it suitable for bench-top use without occupying excessive space.

This power supply is highly suitable for educational institutions, industrial testing, laboratories, production and manufacturing units, and workshops where precision and safety in power delivery are critical.

Microprocessor controlled with USB programmability for precision output adjustment. Flexible auto-ranging output enables voltage or current operation within ratings. Digital encoders and four-digit LCD display provide clear and accurate readouts.

Enhanced safety features including OCP, OVP, and OTP protection mechanisms. Natural convection cooling and wide operating temperature range (0°C to 50°C). Supported AC supply voltages: 90 V to 264 V with IEC 320 plug type.

Compact, attractive desk-top housing built for laboratory and industrial use. Ideal for educational, industrial, laboratory, manufacturing, and workshop applications. Explore more industrial-grade Bench Power Supplies and related measurement instruments on EnvMart for advanced testing and power solution needs.
