EAO 84 Series Illuminated Push Button Switch Momentary Panel Mount SPST 22.5 mm Cutout IP67 42 V dc K84-603.4015



Category Push Button Switch Brand EAO Condition New

Specifications

Country of Origin	India
Brand	EAO
Length	300mm
Model	K84-603.4015
IP Rating	IP67
Mount Type	Panel
Series	84
Contact Configuration	SPST
Contact Rating	200mA @ 42Vac/dc (Max. power 2W)
Panel Cutout Size	22.5 mm
Terminal type	Quick Connect
Standards/Approvals	CB, CE, RoHS, UL
Switch Operation	Momentary
Actuator Colour	White
Contact DC Voltage	42V dc
Actuator Style	Button
Switch Contact Current	200mA
LED Voltage	24V dc
Depth behind panel	31mm

Key Features

The switch features full-face, high brightness LED illumination for clear indication.
It has an IP67 rating ensuring protection against dust ingress and water immersion.
Contact configuration is SPST with gold plated normally open contacts.
Supports contact DC voltage of 42 V dc and contact current rating of 200mA, suitable for low power applications.
The switch has a low profile with a thickness of 2mm and a depth behind panel of 31mm allowing compact installation.
LED operates at 24 V dc ensuring bright illumination and efficient power use.
Quick connect terminal type allows easy and reliable wiring.
Certified to CB, CE, RoHS, and UL standards ensuring reliability and compliance.

Product Description

EAO K84-603.4015 is a reliable illuminated push button switch designed for panel mounting applications requiring a 22.5 mm cutout. This switch operates momentarily with a white button actuator and features a high brightness full-face LED illumination, providing clear visual feedback. The IP67 rating ensures exceptional protection against dust and water, making it ideal for industrial, automation, and electrical control panel systems.

The contact configuration is Single Pole Single Throw (SPST) with gold plated normally open (N/O) contacts rated for 200mA at 42 V dc, offering safe and efficient switching for low power circuits. The LED illumination operates at 24 V dc for vibrant indication while consuming minimal power. The low-profile design with just 2mm height above the panel surface and a 31mm depth behind panel allows compact and flush installation in control panels.

Quick connect terminals simplify installation and maintenance. This push button switch meets industry standards including CB, CE, RoHS, and UL, ensuring quality and regulatory compliance. Its robust design supports use in industrial automation, manufacturing equipment, electrical panels, and other applications requiring durable, illuminated manual control switches.

The switch features full-face, high brightness LED illumination for clear indication. It has an IP67 rating ensuring protection against dust ingress and water immersion. Contact configuration is SPST with gold plated normally open contacts.

Supports contact DC voltage of 42 V dc and contact current rating of 200mA, suitable for low power applications. The switch has a low profile with a thickness of 2mm and a depth behind panel of 31mm allowing compact installation.

LED operates at 24 V dc ensuring bright illumination and efficient power use. Quick connect terminal type allows easy and reliable wiring. Certified to CB, CE, RoHS, and UL standards ensuring reliability and compliance. Durable design with white button actuator style for easy identification and use.

This product is ideal for use in industrial automation systems, electrical control panels, machinery interfaces, and other environments where reliable momentary push button control with illumination is essential. Browse more Push Button Switches and electrical components at EnvMart to find complementary products for your automation needs.
