RS PRO UNITRONIC LiYY Series Data Cable 3 Cores 0.25 mm² 100 m Grey Sheath Polyvinyl Chloride 0028303
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 500V |
| Brand | RS PRO |
| CROSS SECTIONAL AREA | 0.25mm² |
| Model | 0028303 |
| Cable Length | 100m |
| Series | UNITRONIC LiYY |
| Outside diameter | 4mm |
| Maximum Operating Temperature | 80°C |
| Number Of Cores | 3 |
| Conductor Material | Copper |
| Minimum Operating Temperature | -40°C |
| Jacket Material | Polyvinyl Chloride |
| Standards/Approvals | CE |
| Jacket Colour | Grey |
| Fire Behaviour | Flame Retardant |
| Conductor Type | Stranded |
| Number of Strands | 14 |
| Core Strands | 14 x 0.14mm |
| Size of Strands | 0.14mm |
| • Operating temperature with occasional flexing | -5°C to +70°C |
| • Operating temperature in fixed installation | -40°C to +80°C |
Key Features
- The cable has a compact 4 mm outside diameter for space-saving installations.
- It features flame-retardant properties to limit fire spread in the workplace.
- Conductors consist of 14 strands of 0.14 mm copper wire to ensure reliable signal transmission.
- Operating temperature ranges from -40°C in fixed installation up to 80°C, with occasional flexing allowed between -5°C and 70°C.
- The cable operates at a rated voltage of 500 V and is CE certified.
- The grey PVC jacket provides moisture and abrasion resistance for durability in industrial environments.
- A minimum bending radius of 10 times the cable diameter ensures flexibility during installation.
- Ideal for process and control equipment, automotive manufacture, and production industry signal transmission.
Product Description
Lapp 0028303 UNITRONIC LiYY Series Data Cable is a high-quality, flame-retardant data cable featuring three copper conductor cores each with a cross-sectional area of 0.25 mm². The cable length is 100 meters, with a compact outer diameter of 4 mm and a grey polyvinyl chloride sheath that resists moisture and abrasion, enhancing durability in harsh industrial environments.
This stranded conductor cable carries a voltage rating of 500 V and meets CE standards, making it suitable for a wide range of industrial and manufacturing applications. Its flame-retardant properties conform to VDE 0472 part 804, restricting fire spread and improving workplace safety. The cable's flexible design allows installation in confined spaces with a minimum bending radius of 10 times its diameter.
Operating temperature ranges from -40°C to 80°C for fixed installations and -5°C to 70°C when occasional flexing is required, adapting well to various industrial conditions. The conductor consists of 14 strands of 0.14 mm diameter copper wire to ensure excellent conductivity and signal integrity.
Commonly utilized in process and control equipment, production and packaging industries, and automotive manufacturing, this cable excels in transmitting clear data signals reliably and efficiently. Its resilient PVC insulation and sheath provide mechanical protection while enabling space-saving installation.
The cable offers a compact 4 mm diameter suitable for tight space installations. Flame-retardant according to relevant IEC and VDE standards. Stranded copper conductors with 14 strands of 0.14 mm diameter each. Rated for 500 V voltage operating capacity.
Durable grey PVC sheath for moisture and abrasion resistance. Operating temperature from -40°C to 80°C for fixed installation with flexibility for occasional flexing. Minimum bending radius of 10 times the cable diameter to ensure installation flexibility.
Suitable for a wide range of industrial and control signal transmission applications. Set contains 1 piece of Lapp UNITRONIC LiYY Data Cable with 3 cores, 0.25 mm² cross-sectional area, and 100 m length. Explore Lapp cables and data transmission solutions on EnvMart for reliable industrial wire and cable products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The cable has a voltage rating of 500 V, making it suitable for various industrial applications.
For fixed installations, the operating temperature range is from -40°C to 80°C.
This data cable features three cores, each with a cross-sectional area of 0.25 mm².
The cable has a compact outside diameter of 4 mm, allowing for space-saving installations.
The jacket is made of polyvinyl chloride (PVC), which provides moisture and abrasion resistance.
The minimum bending radius is 10 times the cable diameter, ensuring flexibility during installation.
Each conductor consists of 14 strands of 0.14 mm diameter copper wire, ensuring reliable signal transmission.
Yes, the cable is flame-retardant, conforming to relevant IEC and VDE standards to limit fire spread.
It is commonly used in process and control equipment, automotive manufacturing, and production industries for signal transmission.
With occasional flexing, the operating temperature range is from -5°C to 70°C.
The cable is CE certified, ensuring compliance with relevant safety and performance standards.
The cable is manufactured in Germany, reflecting its quality and engineering standards.
