STMicroelectronics 2-Element EMI Filter & ESD Protector, 6-Pin SOT-323 USBUF01W6

STMicroelectronics USBUF01W6 is a 2-element EMI filter and ESD protector designed in a compact 6-pin SOT-323 surface-mount package. Featuring a complex diode array configuration, this device provides reliable transient voltage suppression and superior electrostatic discharge protection for USB interfaces and other sensitive electronic circuits.

Operating efficiently within a temperature range of -40°C to 150°C, the USBUF01W6 filter ensures stable performance in various industrial, commercial, and consumer electronic applications. The clamping voltage of 7.95V protects downstream components from voltage spikes and electrostatic events.

Physical dimensions measure 2.2 mm in length, 1.35 mm in width, and 1 mm in height, enabling integration into space-constrained PCB layouts without compromising electrical protection effectiveness. This series is specifically crafted for EMI filtering and ESD protection, enhancing device longevity and compliance with EMI standards.

Typical applications include transient voltage suppression on USB ports and general circuit safeguarding in industrial equipment, communication devices, and computing instruments. The product's surface-mount design ensures ease of assembly and robust solder joint reliability.

Complex array diode configuration provides advanced EMI and ESD protection. Compact 6-pin SOT-323 footprint compatible with dense PCB designs. Wide operational temperature range from -40°C to 150°C ensures reliability. Clamping voltage of 7.95V for effective transient voltage suppression.

Two elements per chip for enhanced protection capabilities. Small dimensions: 2.2 mm x 1.35 mm x 1 mm for flexible application. Explore EnvMart's extensive inventory of high-quality EMI filters and ESD protection devices to secure your electronic designs with trusted components like the USBUF01W6.
