PITTMAN AMETEK TIP Brushed Geared DC Geared Motor 24V dc 23W 1.1Nm Torque 236rpm Speed 6.34mm Shaft Diameter GM9236S020-R1

PITTMAN AMETEK TIP GM9236S020-R1 is a brushed geared DC geared motor designed to operate at 24V dc with a power rating of 23W. It delivers a maximum output torque of 1.1Nm at a speed of 236rpm and features a 6.34mm diameter shaft. This motor is engineered for industrial automation, robotics, and control gear applications where precision and durability are essential.

This model utilizes a screw mount type, facilitating secure and stable installation in various machinery and equipment. Its spur gearhead coupled with a gear ratio of 19.7:1 ensures efficient transmission of power to meet specific mechanical requirements.

The motor's steel construction provides strength and longevity, making it suitable for demanding environments. Dimensions include a length of 109.9mm and a width of 50.8mm, offering a compact form factor for space-sensitive setups.

The current rating is 240mA, which supports energy-efficient operation. Additionally, it complies with RoHS standards, reflecting its environmentally responsible design.

Part of the GM9000 LO-COG series, this motor incorporates an innovative cartridge brush assembly that reduces noise and extends brush life for reliable performance over time. The motor features 2 pole permanent magnet stators constructed with ceramic magnets enclosed in heavy-gauge steel return rings. Diamond-turned commutators and standard copper graphite brushes further contribute to its long operational life.

The motor ensures smooth and quiet operation suitable for laboratory, industrial automation, robotics, and manufacturing use cases. Its compact size and robust build make it ideal for integration into various electric motor driven systems.

This product is manufactured in the United States, underscoring its quality and precision engineering. Explore the broader range of DC motors and Gear Motors at EnvMart for diverse industrial applications.
