Lapp Unitronic LiHCH Series Low Smoke Zero Halogen Screened Data Cable 4 Pairs 0.14 mm² 50 m Pebble Grey Sheath 0038304

Free Delivery in India | Lowest Global Shipping Charges

Lapp Unitronic LiHCH Series Low Smoke Zero Halogen Screened Data Cable 4 Pairs 0.14 mm² 50 m Pebble Grey Sheath 0038304

Name: Lapp Unitronic LiHCH Series Low Smoke Zero Halogen Screened Data Cable 4 Pairs 0.14 mm² 50 m Pebble Grey Sheath 0038304
Brand: Lapp
SKU: 106965



Category Data Cable Brand Lapp Condition New

Specifications

Country of Origin	Germany
Voltage	250V
Brand	Lapp
CROSS SECTIONAL AREA	0.14 mm²
Model	0038304
Cable Length	50m
Series	Unitronic LiHCH
Outside diameter	6.4mm
Maximum Operating Temperature	80°C
Conductor Material	Bare Copper
Minimum Operating Temperature	-40°C
Jacket Material	Low Smoke Zero Halogen
Standards/Approvals	EU-Directive 2014/35/EU (Low Voltage Directive) and to EU-Directive 2011/65/EU (RoHS, Restriction of the use of certain hazardous substances)
Jacket Colour	Pebble Grey
Screened/Unscreened	Screened
Conductor Type	Stranded
Number of Pairs	4
• Operating temperature range of with occasional flexing	-5°C to +70°C
• Operating temperature range in fixed installations	-30°C to +80°C

Key Features

Cable contains 4 twisted pairs with 0.14 mm² stranded bare copper conductors.
Pebble grey low smoke zero halogen outer sheath enhances safety during fire.
Screened design minimizes electrical interference and ensures signal integrity.
Operating temperature ranges from -40°C to 80°C for versatile use.
Compliant with EU Low Voltage Directive and RoHS for safety and environment.
Flame retardant according to IEC 60332-1-2 standards.
Suitable for data processing, control engineering, and safety-related systems.
50 meters length with a 6.4 mm outside diameter for installation flexibility.

Product Description

Lapp 0038304 Unitronic LiHCH Series screened Data Cable is an industrial-grade low frequency data transmission cable designed with a low smoke zero halogen (LSZH) pebble grey sheath. It incorporates 4 twisted pairs of stranded bare copper conductors with 0.14 mm² cross-sectional area ensuring excellent signal integrity and flexibility. The cable is screened with a braided shield to minimize electrical interference, making it ideal for sensitive and safety-critical applications.

This cable is flame retardant as per IEC 60332-1-2 standards and compliant with EU Low Voltage Directive 2014/35/EU and RoHS Directive 2011/65/EU, confirming its suitability for modern safety and environmental requirements. Its operating temperature ranges from -40°C to 80°C, allowing usage in both fixed installations and occasional flexing.

The outer sheath is made from halogen-free materials delivering low smoke emission in case of fire, making it perfect for public buildings, transport systems, safety-related systems, and other environments where fire safety is paramount. The pebble grey color further aids in identification within cable assemblies.

Applications include data processing, measurement and control engineering, computer systems, instrumentation systems, and office equipment. For optimal performance, accessories such as Lapp’s Skintop EMC cable glands are recommended to maintain cable integrity.

The cable construction reduces capacitance through polyolefin insulation. The braided shield provides robust electrical interference minimization. The LSZH sheath reduces toxic fumes and smoke during fire incidents. Complies with stringent European safety and environmental standards.

Temperature rating supports diverse industrial applications.

Manufactured in Germany, this cable exemplifies quality and reliability in demanding industrial and commercial electrical installations. EnvMart offers this cable for users requiring secure, safe, and high-performance data transmission solutions.
