Molex Type D 19 Way Right Angle Female HDMI Connector 30V 46765-0001
Specifications
| Country of Origin | Singapore |
|---|---|
| Voltage | 30V |
| Size | Type D |
| Brand | Molex |
| Colour | Silver |
| Orientation | Right Angle |
| Current | 800mA |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | 46765 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Contact Plating | Gold |
| Number of Contacts | 19 |
| Contact Gender | Female |
| Connector Gender | Female |
Key Features
- Features 19 contacts for reliable signal transmission.
- Rated for 800mA current and 30V voltage for safe operation.
- Gold-plated copper alloy contacts ensure corrosion resistance.
- Thermoplastic housing provides durability and insulation.
- Designed for surface mount with solder termination type.
- Operates reliably between -30°C to 85°C temperature range.
- Right angle orientation allows space-saving PCB design.
- Supports up to 5000 mating cycles with friction lock design.
Product Description
Molex 46765-0001 HDMI connector Type D 19 Way Right Angle Female 30V is engineered to meet the HDMI 1.4 Specification, making it ideal for compact high-definition video and audio applications.
This connector features 19 gold-plated copper alloy contacts that provide excellent conductivity and corrosion resistance, ensuring reliable signal integrity.
The thermoplastic housing and right angle surface mount design enable compact PCB layouts and robust mechanical strength suitable for demanding industrial and consumer electronics applications. It supports up to 800mA current and operates safely at voltages up to 30V with a temperature range from -30°C to 85°C.
Its design includes friction lock on the receptacle shell to prevent accidental disconnections and delivers a minimum of 5000 mating cycles, enhancing product longevity. This HDMI Type D Micro connector allows engineers to downscale from the larger HDMI Type C connectors, saving board space without compromising performance.
Features 19 contacts for reliable signal transmission. Rated for 800mA current and 30V voltage for safe operation. Gold-plated copper alloy contacts ensure corrosion resistance. Thermoplastic housing provides durability and insulation.
Designed for surface mount with solder termination type. Operates reliably between -30°C to 85°C temperature range. Right angle orientation allows space-saving PCB design. Supports up to 5000 mating cycles with friction lock design.
This product is widely used in industrial, audio/video electronics, consumer electronics, automation, and telecommunications to enable high-quality HDMI connections in compact devices.
Choose from a trusted series 46765 from Molex, origin Singapore, with proven quality compliance. Explore more HDMI Connectors and accessories at EnvMart for your industrial and professional needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HDMI connector is rated for a voltage of 30V, ensuring safe operation in various applications.
It can handle a maximum current of 800mA, making it suitable for a range of electronic applications.
This connector features 19 contacts, which provide reliable signal transmission.
The connector operates reliably within a temperature range of -30°C to 85°C.
It features gold-plated copper alloy contacts for excellent conductivity and corrosion resistance, and a thermoplastic housing for durability.
This model uses a solder termination type, designed for surface mount applications.
The connector has a right angle orientation, allowing for space-saving PCB designs.
It supports up to 5000 mating cycles, enhancing its longevity and reliability in use.
The HDMI connector is manufactured in Singapore, ensuring quality compliance.
It is widely used in industrial, audio/video electronics, consumer electronics, automation, and telecommunications.
This HDMI connector is a female connector, designed for compatibility with other HDMI devices.
This connector belongs to the Molex series 46765, which is designed for compact high-definition applications.
