RS PRO 230 V ac 2 x 15 V ac Toroidal Transformer 2 Output 50 VA 671-8965

RS PRO 671-8965 Toroidal Transformer operates at a primary voltage of 230 V ac and delivers two outputs of 15 V ac each, with a total power rating of 50 VA. It features a toroidal core design that enhances magnetic flux distribution, reducing energy losses and ensuring superior efficiency. The compact and lightweight construction facilitates convenient installation within constrained spaces.

This transformer is designed to minimize electromagnetic interference (EMI) and audible noise, making it ideal for applications requiring quiet operation, such as audio equipment, medical devices, telecommunications, and industrial control systems. The double insulated primary leads and high electrical isolation ensure safe and reliable performance according to stringent international safety standards including RoHS, UL 506, IEC 61558 Class II, and VDE0570 Class II.

With a frequency operating range from 50 Hz to 60 Hz, and reliable copper conductor terminations, the RS PRO 671-8965 transformer supports a variety of commercial and industrial power supply needs. Its dimensions of 80 mm diameter and 33 mm height, combined with a weight of approximately 740 g, allow integration into compact electronic assemblies without compromising performance.

Compact and lightweight design optimizes installation space and costs. Excellent electrical efficiency with toroidal core technology. Reduces electromagnetic interference (EMI) and noise for sensitive electronics. High electrical isolation with double insulated primary leads.

Compliant with RoHS, UL 506, IEC 61558 Class II, VDE0570 Class II safety standards. Two voltage outputs of 2 x 15 V ac with 1.667A current each. Frequency range supports up to 60 Hz operation. Copper conductor termination for reliable connectivity.

Suitable for audio, medical, telecommunications, and industrial use. Lightweight at approximately 740 g with compact dimensions.

Ensure to install with separate mounting hardware as required; mounting hardware is not included. Adhere to safety recommendations to avoid simultaneous contact of both fixing bolt ends with metal chassis to prevent shorted turns.
