BALTECH Infrared Thermal Imaging Camera Basic TR-0120 160X120 infra3

Name: BALTECH Infrared Thermal Imaging Camera Basic TR-0120 160X120 infra3
Brand: ROKADE
SKU: AAEXB
Availability: InStock

Enquire Now

Quantity

Reference AAEXB Category Thermal Imaging Camera Brand ROKADE

rokade-infrared-thermal-imaging-camera-basic-baltech-tr-0120-160x120-infra3

rokade-infrared-thermal-imaging-camera-basic-baltech-tr-0120-160x120-infra3-1

5/5

Free Delivery in India | Lowest Global Shipping Charges

Thermal Imaging Camera

In Stock

Compare

BALTECH Infrared Thermal Imaging Camera Basic TR-0120 160X120 infra3

Reference AAEXB Category Thermal Imaging Camera Brand ROKADE

Specifications

Type	led FPA\|160 x 120 pixels
Voltage	5 B5% DC
Temperature range	-20oc ... +350oc -20oc ... +700oc -20oc ... +1100oc -20oc ... +1200oc
Display	3.5 color LCD \| 270o rotatable
Calibration	Automatic\| based on inputs
Focus	Auto/manual
Humidity	90 (non-condensation)
Battery	Li-ion\| Equal to 3 hours operating time
Spectral range	8-14 m
Lamp	14 cd/m2
Memory capacity	Up to 7000 on SD card
SENSITIVITY	Less Than 0.05oc + 30oc
Operation temperature range	-20o +50oc
Storage temperature range	-40oc +70oc
Area	3 adjustable boxes with max./min./average
Laser type	Class 2\| 1 mV /635\| red
Dimensions L x W x H	125mm x 60mm x 160 mm
Language	English\| Spanish\| German\| French\| Italian\| Russian\| Chinese\| Japanese\| Portuguese\| Korean
USB	Data transfer to and from PC
Vibration	2G IEC68-2-26
Shock	25G IEC68-2-29
Safety class	IP54
Pixel pitch	25 m
Digital zoom	1-2x continous
Measurement spots	4 adjustable spots
Line profile	Horizontal/vertical
Isotherms analysis	Detect high/low temperature/interval
Measurement Modes	Thermal image\| visual image\| thermal fusion\| picture-in-picture\| thumbnail gallery
Emissivity correction	from 0.01 to 1.0
Thermal fusion	IR image shown above\| below or within a temperature interval on a visual image
Picture in Picture	Resizable and movable IR area on visual image
Image frequency	50/60 Hz
Voice annotation	Built-in microphone to record 40sec voice annotation
Charging system	In camera or AC adapter
Electronic zoom	2x
Digital camera	2\|4 mega pixel
Video output	PAL / NTSC
Audio output	yes
FOV	21o x 16o / 0.15 m (standard lens)\| 42o x 32o / 0.1 m (wide-angle lens\| option )\| 10o x 8o / 1 m ( telephoto lens\| option )
Spatial resolution	2.3 mrad
Temperature measurement error	2oc 2% of reading
High temperature alarm	Sound\| color
Color palette	6 colors
Setting of parameters	Date/time\| temperature units oC/oF/K\| language\| scale
Memory type	2G SD card\| Built-in flash
File format	Standard JPEG
Periodic data storage	User definited\| 6 seconds at least
AC power supply	90~260 V AC \| 50/60??\| 5V DC
Power management	Automatic shutdown (user defined)
Weight inc. battery and standard lens	450 g
Tripod mounting	43922

Key Features

High quality thermal image and high accuracy temperature measurement, thermal sensitivity ±2%, 50 mk
Folding and rotatable display Transformer
Auto focus for one-hand operation
Detection of moisture condensation
Laser pointer
Bright LED light
Built-in digital camera 2 Mpixel
Wide temperature range -20oC...+1200oC
Built-in microphone to record 40sec voice annotation

Product Details

The new unique infrared camera BALTECH TR-0120 is intended to investigate thermal fields of objects in the temperature range -20C +1200C. A picture-in-picture function, color folding and rotatable LCD, auto focus, laser pointer and sound alarm make this infrared camera a leader in its class.

Wide-angle and telephoto IR lens
Scalable P-I-P and Thermal fusion
Automatic Hot/Cold/Average temperature detection
Real-time thermal video transfer to PC via USB, and remote transfer via MSN and Skype
Intuitive and easy operating menu
New generation BALTECH Expert software
