Inline Drum Magnetic Separator

Magnetic Drum Separators are of self-cleaning type and provide continuous removal of ferrous contamination from a wide range of free-flowing bulk and granular materials in high-volume applications.Drums can be ordered with or without housing.Magnetic Drum Separator system is a complete machine with Stainless Steel 304 / 316Housing & Drive system. Only drum separator unit can also be supplied.The Drum Separators are available in two types:High Intensity (Ndfeb Magnet 5500 gauss), for Operating Temperature of 80?C(Max.)Low Intensity - (Ferrite Magnet - 2500 gauss), for Operating Temperature of 250?C(Max.)Ferrous fine particles, nuts, bolts, pins, nails and other tramp metal from free-flowing granular material can be arrested effectively.When material flows onto the drum, a stationary magnetic assembly inside the unit's shell captures tramp metal and holds it securely to the drum's stainless steel surface. With contaminants removed, the good product falls freely to a discharge point. As the drum rotates, cleats sweep the ferrous debris through and out of the magnetic field. The tramp metal is discharged separately, creating continuous self-cleaning separation.FeaturesMagnetic Drums have the following featuresDesigned for continuous separation and self cleaning. Ideal for high-flow, heavy-contamination applications. It comes with Stainless steel drum and mild steel or stainless steel housingsMaximum Recovery of Ferrous MetalsMinimum MaintenanceThey require minimum space and are simple to operate.They are flexible enough to be applied for various purposesAdvantagesHelps in removing ferrous particles from any non ferrous powder and granulesIdeal for plastic, food, fertilizer, pharmaceutical, chemical, glass and continuous process plantsProvide utmost protection to crushers, grinders, pulverizes, and allied equipmentCan be used for mining and ore dressing industryEliminate fire hazards and explosions in plants dealing with explosive material.Save money, time and labour by reducing break-down time and improving qualityConstructionThe magnetic drum separator consists of a rotating drum and stationary drum magnet designed as per the specific needs of the customer. The Drum separator is supplied with drive system and SS 304/316 housing along with feed regulating valve.The following Information is requiredType of material from which Iron is to be separated. (Sticky, Granular, Free flowing, Lumps etc)Size and level/percentage of contaminationFlow rate of materialSize/Density of the material particle
