Microprocessor Flame Photometer

Name: Microprocessor Flame Photometer
Brand: Globe Instruments
SKU: AACMT
Price: 43720 INR
Availability: InStock

₹60,001

₹43,720 Save ₹16,281

Tax included

Quantity

Specifications

Brand	Globe Instruments
Power	230V AC\| 50 Hz
Weight	6.25 kg
Accuracy	Less Than 2% of FS
Product Type	Microcontroller Based / Microprocessor Based
Resolution	0.1 ppm / 0.1 meq.
Calibration	Upto 5 Point Calibration
Measurement Range	0 - 100 ppm
Fuel Type	LPG
Ignition System	Auto Ignition
Mode	General/Serum/Urine
Wavelength Range	0-100 ppm and upto 250 meq/l
SENSITIVITY	+-5 ppm
Usage/ Application	Forensic\| Diary\| Cement \| Water\| Food/Fruits\| Biological\| Serum and Urine\| Soil Applications
Filters	Narrow Bandwidth interference glass filters (Calcium and Lithium at extra cost)
Reproducibility	Less Than 1% coefficient of variation for 20 consecutive samples using 10 ppm Na set as Maximum Standard
Detector	Silicon Photodiode
Mobility	Benchtop
Flame System	LPG and Dry Oil Free Air
Displayed Resolution	128x64 Graphical LCD with Backlit
Gas Control	Controlled by Precision Regulator
Curve Accuracy	Less Than 2% of FS
Determination	General/Serum/Urine
Atomizer	Axial Flow Type

Key Features

Bulk Quantities Available

Reference AACMT Category Flame Photometer Brand Globe Instruments

Product Details

Microprocessor Flame Photometers come with Flame Failure detection and an Auto Gas Cutoff Facility. In the event of a power failure, the gas is cut off automatically. In case the flame goes off accidentally during work, the flame failure alarm sounds after a few seconds. Microprocessor Flame Photometer 1600-G are used for the determination of sodium, potassium, calcium, lithium, and barium. They use the latest microcontroller technology and advanced engineering techniques so as to give enhanced accuracy and reproducibility. They have soft touch membrane keys for ease of operation. The solution is aspirated through an atomizer. Air, sample and the fuel are mixed in the mixing chamber which is then sprayed as a very fine mist into the flame. Radiations from the flame passes through specific narrow band interference filter and pass to the photo-detector. The final results are displayed on the 128 x 64 alphanumeric LCD. The standard model comes with 2 filters (Na, K). Additional filters (Ca and Li) are optional at an extra cost. A photoelectric flame photometer is a device used in inorganic chemical analysis to determine the concentration of certain metal ions.
