SKF Spherical Roller Bearing 22315 E/C3 75 mm ID, 160 mm OD, C3 Clearance, Tapered Bore

SKF 22315 E/C3 Spherical Roller Bearing is engineered to deliver reliable operation in demanding industrial applications. Featuring a 75 mm inside diameter and a 160 mm outside diameter, this bearing is designed for heavy-duty machinery where high loads and robust performance are required. The C3 internal clearance allows the bearing to withstand dynamic and static loads efficiently while minimizing friction and heat buildup.

Constructed with high quality steel, the bearing includes two rows of symmetrical rollers, a sphered outer ring raceway, and inclined inner ring raceways. This construction enhances load distribution, ensures smooth rotation, and extends bearing lifespan even under adverse conditions. The tapered bore design makes installation on shafting more adaptable and secure, which is especially useful in systems with misalignment or vibration.

The bearing's 55 mm race width and precise engineering provide superior rotary motion required for mechanical and fluid power equipment, conveyor assemblies, construction machinery, and manufacturing lines. Rated for a dynamic load capacity of 462 kN and a static load rating of 475 kN, this bearing can perform at limiting speeds up to 4300 rpm, making it suitable for high-speed and high-load operations.

SKF's advanced materials and manufacturing processes assure both the durability of the steel roller and bearing components and their ability to resist wear and corrosion over time. The spherical roller design helps to accommodate misalignment between the shaft and housing, reducing maintenance needs.

Applications for the SKF 22315 E/C3 Spherical Roller Bearing span mechanical, fluid power, construction, manufacturing, and industrial sectors, particularly where robust rotary machinery and reliability are vital. This bearing is also widely adopted in HVAC systems, material handling, water treatment, and heavy equipment assemblies.

Spherical roller bearing with advanced steel construction for high load capacity. 75 mm inside diameter and 160 mm outside diameter suitable for robust rotary machinery. C3 internal clearance ensures optimal performance under heavy loads.

Tapered bore type enables secure mounting and straightforward installation. Single row bearing with a race width of 55 mm for precise rotary motion. Rated for dynamic load capacity up to 462 kN and static load up to 475 kN.

Supports limiting speeds of up to 4300 rpm for high-speed industrial applications. Steel rollers and bearing material guarantee wear resistance and long service life. Ideal for industrial, mechanical, construction, and manufacturing environments.
