FAG Taper Roller Bearing 31308-XL, 40 mm ID, 90 mm OD, Steel Cage, Open End

Free Delivery in India | Lowest Global Shipping Charges

FAG Taper Roller Bearing 31308-XL, 40 mm ID, 90 mm OD, Steel Cage, Open End



Category Roller Bearings Brand FAG Condition New

Specifications

Country of Origin	India
Brand	FAG
Model	31308-XL
Series	313
Outside diameter	90mm
Inside Diameter	40mm
End Type	Open
Bore Type	Tapered
Bearing Type	Taper
Cage Material	Steel
Static Load Rating	83kN
Better World Claim	Extended Product Life, Saves Energy
Cone Width	25.25mm
Bearing Dynamic Load Rating	89kN

Key Features

Designed for both radial and axial force support and precise axial shaft guidance.
Tapered bore type optimizes load distribution and rigidity.
Robust steel cage enhances durability and performance.
Static load rating of 83 kN and dynamic load rating of 89 kN provide excellent load handling.
Cone width of 25.25 mm ensures a compact and rigid arrangement.
Open end design increases versatility in varied bearing arrangements.
Extended product life and saves energy under Better World claim.
Suitable for clearance-free or preloaded installations for high running accuracy.

Product Description

The FAG 31308-XL Taper Roller Bearing is a high-performance bearing engineered for supporting combined radial and axial loads. With an internal diameter of 40 mm and an external diameter of 90 mm, this bearing is well-suited for precise shaft guidance and compact arrangement designs required in industrial machinery. Its robust steel cage material ensures durability and reliability under heavy-duty operation.

This bearing features a tapered bore type, which enhances load distribution and axial rigidity. The cone width of 25.25 mm contributes to its compact and economical fit, making it ideal for environments requiring strong axial support and accurate shaft positioning. The open end design enables varied installation and maintenance setups, adding versatility to the bearing’s application range.

Rated with a static load capacity of 83 kN and a dynamic load capacity of 89 kN, the 31308-XL model is suited to applications where high running accuracy and minimal clearance or preload are critical. It is particularly recommended where the load carrying capacity of angular contact ball bearings is inadequate or the higher speed suitability of those bearings is not required. The robust steel cage resists wear and provides excellent stability, while the design minimizes energy consumption and extends product lifetime, supporting sustainability goals.

Applications include automotive, industrial machinery, conveyor systems, rotary housing units, and construction equipment, especially in installations that operate clearance-free or under preload. The bearing arrangement provides superior axial guidance and rigidity, making it ideal for industrial and mechanical power transmission systems in manufacturing, water treatment, and other sectors.

Industrial buyers and engineers will appreciate the FAG 31308-XL’s precision, energy-saving design, and extended product life. Its compliance with the Better World claim further highlights its suitability for sustainable production environments.
