Mextech Digital Tension Meter TT900
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 0~4.4Lbf | 0.001kgf | 1gf | 0.01N | 0.001Lbf |
| Accuracy | ±1.5% or better |
| Over Range Indicator | Buzzer Alarm |
| Display | Blue Back light LCD |
| Size | Main Unit- 149x70x30mm Sensor- 102x81x34mm |
| Brand | Mextech |
| Power Supply | 4x1.5 AAA(UM-4) Battery |
| Model | TT900 |
| Maximum Speed | 2000m/min |
| Temperature | Zero-less than +0.3% FS/°C |
| Weight | 400g |
| Operation temperature | 0~40°C |
| Operation humidity | less than 80% |
| Measuring Principle | Strain gauge |
| Roller Material | Stainless Steel (Standard) Plastic (Optional) |
| Data output | USB / Bluetooth |
| Power off | 10 Minutes Auto / Manual |
| Measuring Frequency | 16 m sec (62.5 samples/sec) |
| Display Update Rate | 0.5 / 1.0 / 2.0 or 4.0 seconds / selectable |
| Overload Capacity | 150% of Full Scale |
| Memory System | Current Value / Max. Value |
| Tension Range | 0~2.0kgf | 0~2000gf | 0~19.6N |
| Sensing Roller | Deflectionof SensingRoller(max.) 0.2mm |
| Coefficient | Span- less than +0.01% FS/°C |
Key Features
- Measures tension in wires, cables, and strings.
- Digital display for precise tension readings.
- Built-in memory for storing test results.
- Adjustable settings for different materials.
- Compact and lightweight for portability.
- High accuracy with adjustable measurement ranges.
- Includes a strap for secure handling during use.
Product Description
The Mextech TT900 Digital Tension Meter is a professional tool designed to measure tension in wires, belts, ropes, and cables. It employs the ‘three-roller principle’ for high accuracy and resolution, providing digital readings with no guessing. Powered by 4 AAA batteries, it offers four measurement units (N, kg, lb, g) and displays current, max, peak, and min values simultaneously. The meter takes 62 measurements per second and shows the average. With USB and Bluetooth data output, 10-minute auto power-off, and a durable ergonomic design, it’s ideal for textiles, printing, elevators, and packaging.
Available on EnvMart, these Tension Meters are ideal for measuring tension accurately in cables, wires, and other materials. Mextech Tension Meters provide precision and reliability, making them perfect for industrial, laboratory, and engineering applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Mextech TT900 has a tension measurement range of 0 to 2.0 kgf, 0 to 2000 gf, and 0 to 19.6 N.
The accuracy of the Mextech Digital Tension Meter TT900 is ±1.5% or better.
The Mextech TT900 is powered by 4 AAA (UM-4) batteries.
The resolution of the Mextech TT900 is 0 to 4.4 Lbf, 0.001 kgf, 1 gf, 0.01 N, and 0.001 Lbf.
The Mextech TT900 features a blue backlight LCD display for easy reading of measurements.
The Mextech Digital Tension Meter TT900 can measure at a maximum speed of 2000 m/min.
The operating temperature range for the Mextech TT900 is 0 to 40°C, and the operating humidity is less than 80%.
Yes, the Mextech TT900 has USB and Bluetooth data output capabilities.
The weight of the Mextech TT900 is 400 grams.
The size of the main unit of the Mextech TT900 is 149 x 70 x 30 mm, and the sensor measures 102 x 81 x 34 mm.
The Mextech TT900 includes a built-in memory system for storing current and maximum values, as well as an overload capacity of 150% of full scale.
The measuring frequency of the Mextech TT900 is 62.5 samples per second, or 16 m sec.
