Labtron LPHT-A10 Digital Pencil Hardness Tester
Specifications
| Country of Origin | UK |
|---|---|
| Brand | Labtron |
| Power Supply | AC 220V ± 5% / 50 to 60 Hz |
| Model | LPHT-A10 |
| Overall dimensions | 540 × 260 × 650 mm |
| Type of Product | Hardness Tester |
| Data output | LCD display / built-in printer |
| Test Force | 0.245 / 0.49 / 0.98 / 1.96 / 2.94 / 4.98 N |
| Hardness Test Range | 40 to 700 HK |
| Executive Standard | GB/T 26704 2011 Pencil |
| Test Force Application Method | Automatic (loading / holding / unloading) |
| Minimum Test Unit | 0.01 μm |
| Indenter and Lens Conversion | Automatic |
| Microscope Magnification | 100× (observation / test) / 200× (test) |
| Test Force Holding Time | 1 to 99 s (10 s recommended) |
| X-Y Test Bench Size | 100 × 100 mm |
| X-Y Test Bench Maximum Movement | 25 × 25 mm |
| Effective Height of Workspace | 100 mm |
| Distance from Indenter to Outlet | 130 mm |
| Weight of Main Engine | 50 kg |
Key Features
- Automated measurement and control
- Clear, saveable indentation images
- Generates detailed test reports
- High-precision guiding mechanism
- Dual optical path functionality
Product Description
The Digital Pencil Hardness Tester LPHT-A10 is designed for precision testing within a hardness range of 40 to 700 HK. It operates with six selectable test forces: 0.245, 0.49, 0.98, 1.96, 2.94, and 4.98 N. With a minimum test unit of 0.01 µm, it delivers exceptional measurement accuracy. The system features automatic loading, holding, and unloading of test forces, along with automatic indenter and lens conversion for user convenience. Ideal for pencil hardness testing in compliance with international standards.
Applications:
Our Digital Pencil Hardness Tester LPHT-A10 is perfect for assessing pencil lead hardness with precision and consistency. The product has been widely used in the domestic pencil manufacturing industry for quality control and performance evaluation.
