Labtron Semi-automatic Microtome LSAM-B11 image-1

Free Delivery in India | Lowest Global Shipping Charges

Semi-automatic Microtome ESAM-B11

Name: Semi-automatic Microtome ESAM-B11
Brand: Generic Brand
SKU: ADGJX
Price: 69.5 USD
Availability: InStock



SKU ADGJX Category Microtome Brand Generic Brand Condition New

Specifications

Country of Origin	UK
Power Consumption	100 W
Display	OLED Display
Brand	Generic Brand
Power Supply	AC 110/220V ± 10% / 50/60Hz
Precision	±5%
Model	LSAM-B11
Gross Weight	45 Kg
Type of Product	Microtome
Specimen orientation	XY — 8°C / rotation ±90°C
External dimension (W x D x H)	575 x 420 x 330 mm
Specimen Vertical Stroke	70 mm
Specimen Horizontal Stroke	28 mm
Whole Layer Clearance Distance	10 to 6000 µm (10 / 12 / 15 / 20...6000 / after 15 µm the increment is 5 µm)
Sectioning Thickness Range (0.25 to 100 µm)	0.25 to 2.5 µm increment 0.25 µm / 2.5 to 5 µm increment 0.5 µm / 5.0 to 10 µm increment 1 µm / 10 to 30 µm increment 2 µm / 30 to 60 µm increment 5 µm / 60 to 100 µm increment 10 µm
Minimum Sectioning Thickness	0.25 µm
Maximum Specimen Size	70 x 70 mm
Feed Speed	1500 µm/s / 3500 µm/s
Package Dimension (W x D x H)	670 x 550 x 480 mm
Trimming Thickness Range (1 to 900 µm)	1 to 10 µm increment 1 µm / 10 to 20 µm increment 2 µm / 20 to 50 µm increment 5 µm / 50 to 150 µm increment 10 µm / 150 to 600 µm increment 50 µm

Key Features

Smooth running hand wheel
Provides optimal tactile response
Specimen trimming feature speeds up productivity
Automatic sectioning speed is adjustable by gentle button
Fast switching between paraffin block clamp and cassette clamp
Auto slicing control ensures fast trimming and slicing switching
Safety and emergency braking systems
3 mode control system: conventional mode, intelligent sensing mode, and whole layer cutting mode
Lateral displacement of blade holder base enables better sectioning
Provides work flow flexibility
The precise positioning system not only easy to use, but also provides accurate X and Y axis adjustment
Imported guide rails for cross-rollers and high-precision screw motion mechanisms
Large-volume removable waste tray, on the top of the housing
Red bar on the blade holder covers the whole length of blade to protect the user and enables easy changing of the blade
Safety and emergency braking systems

Product Description

The Semi-Automatic Microtome LSAM-B11 provides a streamlined design with exceptional ergonomic attributes for comfortable use and repeatable precision during sectioning. It is a rotary microtome equipped with imported roller guide rails and high-precision roller screws that combines mechanical feed with manual cutting to generate high-quality ribbons. The hand wheel is designed to run smoothly, reducing hand stress and allowing for maximum efficiency and production.

Applications:

Semi-auto microtomes are extensively used in clinical fields, research laboratories, industrial laboratories, pathology labs, medical institutions, histology and biology labs, and many medical science applications.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The sectioning thickness range for the Semi-automatic Microtome LSAM-B11 is from 0.25 to 100 µm, with various increments depending on the thickness range.

This model operates on a power supply of AC 110/220V ± 10% and has a power consumption of 100 W.

The maximum specimen size that this microtome can accommodate is 70 x 70 mm.

The external dimensions of the Semi-automatic Microtome LSAM-B11 are 575 x 420 x 330 mm.

The trimming thickness range for this model is from 1 to 900 µm, with increments varying from 1 µm to 50 µm depending on the specific thickness range.

The feed speed for the LSAM-B11 is 1500 µm/s and 3500 µm/s, allowing for efficient sectioning.

This model is equipped with an OLED display for clear visibility of settings and operations.

The precision of the Semi-automatic Microtome LSAM-B11 is rated at ±5%.

The specimen vertical stroke for this microtome is 70 mm.

This model includes safety and emergency braking systems to enhance user safety during operation.

The gross weight of this microtome is 45 kg.

The LSAM-B11 is suitable for clinical fields, research laboratories, industrial laboratories, pathology labs, and medical institutions, among other applications.
