SKF Tapered Roller Bearing 110 mm ID, 180 mm OD, 56 mm Race Width, Closed End Type 23122 CCK/W33

SKF 23122 CCK/W33 is a high-quality Tapered Roller Bearing designed for demanding industrial and mechanical applications. With a precise inner diameter of 110 mm and an outer diameter of 180 mm, this bearing provides robust support and efficient load handling.

The bearing features a tapered bore type to ensure accurate shaft fitting and a race width of 56 mm to maintain structural integrity under heavy loads. Its closed end design protects the internal rollers from dust and contaminants, enhancing longevity and reliability.

This model incorporates two rows of symmetrical rollers and a common sphered outer ring raceway with two inner ring raceways inclined at an angle to the bearing axis. This design enables it to accommodate shaft misalignment and heavy radial and axial loads effectively.

With a dynamic load rating of 450 kN and a static load rating of 585 kN, the bearing performs optimally in high-load conditions and operates at speeds up to 3600 rpm. Manufactured in Sweden, this bearing meets stringent quality requirements for reliability and performance.

The SKF 23122 CCK/W33 bearing is widely utilized in industrial sectors including renewable energy, mining, mineral processing, cement manufacturing, material handling, pulp and paper production, metals, and marine machinery. Its robust construction and ability to handle misalignment reduce maintenance costs and extend service life.

Features a tapered bore for precise shaft fitment. Race width of 56 mm assures durability during use. Closed end design protects from contamination. Operates reliably at speeds up to 3600 rpm. Dynamic load rating of 450 kN and static load rating of 585 kN.

Two rows of symmetrical rollers for load distribution. Manufactured in Sweden ensuring high quality standards. Suitable for heavy-duty industrial applications. Reduces maintenance costs due to long service life. Explore EnvMart’s extensive range of industrial bearings and mechanical spares to find high-performance components that meet your application requirements.
