Meech A8 600 mm Air Knife Aluminium Material 6.8 bar Max Operating Pressure A85024

Meech A8 A85024 600 mm Air Knife is an industrial-grade air curtain designed to provide an efficient blade of air through a narrow slot to control ambient air and remove unwanted particles in production or recycling environments.

This air knife operates at a maximum pressure of 6.8 bar and delivers an inlet air flow of 58 cfm. It employs a 0.002 mm slot gap along its entire length of 600 mm to release compressed air, creating an area of low pressure behind the air blade, retaining ambient air at a ratio of up to 25:1, substantially amplifying airflow.

Constructed from quality aluminium material, the A8 series is flange mountable for ease of integration within various industrial settings. The inlet port size is 1/4 inch BSP thread standard, facilitating compatibility with common pneumatic connections. Noise emission is measured at a low 50 dBA, supporting quieter work conditions.

Typical applications include use in recycling facilities for moving lighter or smaller particles, removing foreign matter from products or clean areas, and other industrial manufacturing processes requiring controlled air curtains.

Durable aluminium construction for robust industrial use. Operating pressure up to 6.8 bar enhances air discharge effectiveness. Extremely fine slot gap of 0.002 mm for precise air blade formation. High amplification ratio (25:1) maximizes air volume delivered.

Compatible 1/4 inch BSP inlet port supports standard pneumatic systems. Quiet operation with 50 dBA noise level. Flange mount design ensures secure installation. Compact design with 42 mm overall height. Length of 600 mm suits diverse industrial implementations.

Manufactured in the United Kingdom, assuring quality.

This air knife is part of the Meech A8 series known for energy-efficient Air Curtains that contribute to cleaner processes and controlled particle handling. Suitable for industrial, manufacturing, recycling, and HVAC system applications where precise air flow control is critical.
