Durbal M12 x 1.75 Male Forged Steel Rod End Metric, 12mm Bore BRM 12-00-501

Durbal BRM 12-00-501 male forged steel rod end metric with a 12mm bore provides a premium line rod end solution designed for demanding industrial and mechanical applications requiring robust and low maintenance bearing connections.

This rod end features a forged steel housing that is tempered, case hardened, and surface galvanized to provide excellent durability and resistance to wear and corrosion. The bearing race inside the housing is ground and lapped while the rolled threaded male connection uses a standard metric M12 x 1.75 right-hand thread, ensuring high strength and secure installation.

The inner ring consists of ball bearing steel, hardened and superfine ground to guarantee smooth self-aligning bearing operation and low friction performance. It is compatible with lubricants such as Polyrex EP2 or soap complex grease, extending its functional life under continuous use.

The rod end is engineered for dynamic load capacities up to 5 kN and static load ratings of 1.8 kN, suitable for many industrial, manufacturing, and mechanical engineering uses including machine tool assemblies, automation equipment, and fluid power connectors.

Operating temperature ranges from -20°C up to 120°C, making it reliable across diverse working environments. The bearing clearance is specified between 15 to 40 μm radial, optimizing alignment and load distribution while minimizing wear.

This performance rod end carries the German country of origin designation and is ideal for engineers and technicians seeking high-quality rotary bearings and housing units compatible with metric thread standards.

Constructed with forged steel for enhanced durability and toughness. Features a 12mm bore diameter for precise shaft fitting. Supports dynamic load rating of 5kN and static load rating of 1.8kN. Right-hand threaded male connection compliant with metric thread standards.

Operates reliably within temperature range of -20°C to 120°C. Rod end housing is tempered, case hardened, ground, and surface galvanized for corrosion resistance. Includes ball bearing steel inner ring, hardened and superfine ground for smooth alignment.

Lubrication possible with Polyrex EP2 or soap complex grease for longevity. Features bearing clearance of 15 - 40 μm radial for optimal movement. Explore EnvMart for quality Rod Ends like this Durbal BRM 12-00-501 suitable for industrial, mechanical, and fluid power applications.
