Durbal Metric Male Forged Steel Rod End M8 x 1.25 Thread, 8mm Bore, Left Hand Thread BRM 08-00-502

Durbal BRM 08-00-502 is a premium line metric male forged steel rod end designed for demanding industrial and mechanical use cases. Featuring an M8 x 1.25 left hand male thread and an 8mm bore diameter, this rod end provides reliable rotary bearing performance with low maintenance requirements due to its greasable design. Constructed from forged steel, the rod end housing is tempered, case hardened, surface galvanized, and includes a bearing race that is ground and lapped to precise tolerances. The inner ring is made from ball bearing steel, hardened and superfine ground to optimize durability and performance.

This rod end is rated for a dynamic load of 4 kN and a static load of 1 kN, making it suitable for various mechanical, fluid power, and industrial applications including manufacturing, construction equipment, and machinery maintenance. It supports operation within a temperature range from -20°C to 120°C, ensuring robustness under varying thermal conditions. The bearing clearance is tightly controlled between 15 and 40 micrometers radially, contributing to smooth rotary motion and alignment.

Lubrication is facilitated with Polyrex EP2 or compatible soap complex grease, enhancing longevity and reducing wear. The unit’s dimensions include an overall width of 54mm and an outside diameter of 24mm, making it a precise fit for assembly requirements. This rod end is manufactured in Germany and does not carry specific standards or approvals but is engineered to high-quality specifications.

Made from forged steel for enhanced strength and durability. Includes a left hand M8 x 1.25 male thread for secure fastening. Dynamic load rating of 4 kN and static load rating of 1 kN ensure reliability. Operating temperature range from -20°C to +120°C supports diverse environments.

Rod end housing is tempered, case hardened, and surface galvanized. Hardened ball bearing steel inner ring with superfine ground surface. Lubrication with Polyrex EP2 or soap complex grease is supported. Bearing clearance is 15 - 40 micrometers radial for precise movement.

Overall width measures 54mm and outside diameter is 24mm for proper fit.

This product is suitable for use in industrial sectors such as mechanical machinery, fluid power systems, construction, and manufacturing. Explore the wide range of Rod Ends available for various mechanical applications on EnvMart.
