Siemens 3 Phase Digital LCD Energy Meter 7KT1672, 5A Rated Current, 90.6x72.3mm Cutout, Pulse Output
Specifications
| Country of Origin | Italy |
|---|---|
| Display Type | LCD |
| Brand | Siemens |
| Model | 7KT1672 |
| Depth | 63mm |
| Number of inputs | 1 |
| Series | 7KT PAC1600 |
| Maximum Operating Temperature | 55°C |
| Meter Type | Digital |
| Minimum Operating Temperature | -25°C |
| Digit height | 85mm |
| Number of outputs | 2 |
| Number of Phases | 3 |
| Standards/Approvals | CE |
| Cutout Height | 90.6mm |
| Cutout Width | 72.3mm |
Key Features
- The meter features an LCD display supporting 10 digits for clear readability.
- Designed for three-phase systems with 5A rated current for industrial power monitoring.
- Equipped with pulse output for high-precision energy consumption analysis.
- Suitable for DIN rail mounting enabling easy installation in electrical panels.
- Operates reliably within the temperature range of -25°C to +55°C for versatile environmental tolerance.
- Capable of measuring both apparent and active energy for comprehensive monitoring.
- Compact with a cutout dimension of 90.6mm height and 72.3mm width, and 63mm depth.
- Certified with CE standards ensuring quality and safety compliance.
Product Description
Siemens 7KT1672 digital LCD energy meter is a high-quality measuring device designed for the efficient monitoring of three-phase electrical systems with a rated current of 5A. It features a robust LCD display capable of showing 10 digits, making energy readings clear and easy to interpret. Compact in size with a cutout height of 90.6mm and width of 72.3mm, and a depth of 63mm, it fits seamlessly into various industrial applications.
This energy meter includes a pulse output that allows for precise energy consumption tracking and data integration into energy management systems. It is specifically built for mounting on DIN rails, which facilitates quick installation in control panels.
Engineered to operate under demanding environmental conditions, the meter maintains accurate function over a temperature range from -25°C up to +55°C, supporting diverse industrial and commercial environments.
It measures both apparent and active energy, offering versatility for detailed analysis of power usage in electrical distribution networks. Its CE certification ensures adherence to recognized European safety and quality standards.
Typical applications include energy monitoring in manufacturing plants, electrical substations, HVAC systems, and infrastructure requiring detailed energy analytics for operational efficiency.
The meter features an LCD display supporting 10 digits for clear readability. Designed for three-phase systems with 5A rated current for industrial power monitoring. Equipped with pulse output for high-precision energy consumption analysis.
Suitable for DIN rail mounting enabling easy installation in electrical panels. Operates reliably within the temperature range of -25°C to +55°C for versatile environmental tolerance. Capable of measuring both apparent and active energy for comprehensive monitoring.
Compact with a cutout dimension of 90.6mm height and 72.3mm width, and 63mm depth. Certified with CE standards ensuring quality and safety compliance. Explore our range of industrial measuring instruments and Energy Meters to find quality solutions tailored to your operational needs at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This energy meter is designed for three-phase systems with a rated current of 5A.
The cutout dimensions are 90.6mm in height and 72.3mm in width, with a depth of 63mm.
It features an LCD display that supports 10 digits for clear readability.
It operates reliably within a temperature range of -25°C to +55°C.
This model is capable of measuring both apparent and active energy for comprehensive monitoring.
It is designed for DIN rail mounting, allowing for easy installation in electrical panels.
This meter is equipped with two outputs for pulse output, facilitating high-precision energy consumption analysis.
It is certified with CE standards, ensuring quality and safety compliance.
The model belongs to the 7KT PAC1600 series.
The country of origin for this model is Italy.
The digit height of the display is 85mm, enhancing visibility.
Typical applications include energy monitoring in manufacturing plants, electrical substations, and HVAC systems.
