Impel 5HP 4 Pole Foot Mounting DC Break Motor Frame Size 112M
Specifications
| Frequency | 5OHZ+-5% |
|---|---|
| Warranty | 2 years |
| Brand | Impel Motors |
| Voltage (V) | 415+-10% |
| Body Material | Cast Iron |
| Mounting | Foot Mounting (B3) |
| Protection Type | IP55 |
| Altitude | 1000M above sea level |
| Power Rating (kW) | 3.7 kW |
| Power (HP) | 5 HP |
| Motor Type | AC Induction DC Brake Motor (with Emco make brake) |
| Ambient Temperature (ºC) | 50 ºC |
| Rated Speed (RPM) | 1500 RPM |
| No. of Poles | 4 |
| Supply | 3 Phase AC |
| Duty Type | S1 (Compatible to S4) |
| Class of insulation | F |
| Frame Size (ISI) | 112M |
| Temperature rise | Limited to class B |
| Break Size (No.) | 16 |
Key Features
- High Efficiency and Long Life
- High Torque Level
- High Power Factor
Product Description
Impel 5HP 4 Pole Foot Mounting DC Break Motor Frame Size 112M From Impel used for Industrial Purposes. Envmart is a well-known e-commerce platform for a qualitative range of Impel General Purpose Motors For Industrial or domestic Applications. All Impel Motors Are manufactured using quality assured material and advanced techniques, which make them up to the standard in this highly challenging field of Industrial and Manufacturing Units
- Low Temperature Rise
- Easy maintenance
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a power rating of 5 HP, which is equivalent to 3.7 kW.
It is an AC Induction DC Brake Motor with an Emco make brake.
The rated speed of this motor is 1500 RPM.
The motor operates at a voltage of 415V with a tolerance of ±10%.
The frequency specification is 50Hz with a tolerance of ±5%.
This motor features a foot mounting configuration (B3).
The motor has a protection rating of IP55.
The maximum ambient temperature for this motor is 50 ºC.
This model can operate at altitudes up to 1000 meters above sea level.
The insulation class of this motor is Class F.
The duty type is S1, and it is compatible with S4 duty type.
The body of this motor is made from cast iron.
