EMERSON ? ASCO Pneumatic Solenoid Valve 5/2 Solenoid G 521 Series 24V dc 1/4 in Port Size 1050 L/min 8 bar 1.6W 52100001
Specifications
| Country of Origin | Poland |
|---|---|
| Voltage | 24V dc |
| Brand | EMERSON ? ASCO |
| Body Material | Anodised Aluminium |
| Maximum Operating Pressure | 8 bar |
| Height | 56.5mm |
| Length | 131.3mm |
| Model | 52100001 |
| Width | 22mm |
| Mount Type | Manifold |
| Series | 521 |
| Number Of Ports | 5 |
| Maximum Operating Temperature | 50°C |
| Port Type | Push-in |
| Port Size | 1/4 in |
| Seal Material | Nitrile Rubber (NBR) |
| Minimum Operating Temperature | 5°C |
| Actuation Type | Solenoid |
| Maximum Flow Rate | 1050L/min |
| Connection Thread Standard | G |
| Mount Pattern | DIN |
| Minimum Pilot Pressure | 1.5bar |
| Valve Function | 5/2 |
| Electrical Connection Type | Plug Connector |
| Available in 3 different sizes | M5, G1/8" or G1/4" |
| Solenoid Power Consumption | 1.6W |
Key Features
- Operates at 24V dc voltage supplying 1.6W power consumption.
- Features a 5-port, 2-position configuration suitable for manifold mounting.
- Constructed from anodised aluminium with nitrile rubber (NBR) seals for durability.
- Maximum operating pressure up to 8 bar and flow rate of 1050 L/min ensure efficient performance.
- Compact dimensions of 131.3mm length, 56.5mm height, and 22mm width.
- Operates within temperature range from 5°C to 50°C for versatile applications.
- Equipped with plug connector electrical connection and DIN mount pattern.
- Valve function 5/2 supports monostable and bistable operation modes.
Product Description
EMERSON ASCO 52100001 Pneumatic Solenoid Valve 5/2 Series 521 operates at 24V dc and power consumption of 1.6W, providing reliable actuation in pneumatic fluid control systems. It is designed for manifold mounting with a 5-port, 2-position configuration delivering efficient pneumatic flow management.
The valve body is made of durable anodised aluminium and utilizes nitrile rubber (NBR) seals, ensuring long service life and resistance to wear. With a maximum operating pressure of 8 bar and a maximum flow rated at 1050 L/min, this valve is suitable for demanding industrial applications.
Compact with a length of 131.3mm, height of 56.5mm, and width of 22mm, the valve is operable within temperatures ranging from 5°C to 50°C. It features a plug connector electrical interface and a DIN mount pattern, facilitating straightforward integration into pneumatic manifolds and systems.
The 5/2 valve function supports both monostable and bistable actuation, suitable for pneumatic control in automation, manufacturing, and fluid power industries. It is a part of the 519-520-521 series offering versatility with 3/2, 5/2 and 5/3 mini distributor configurations.
Operates at 24V dc voltage with 1.6W power consumption. Manifold mountable with 5 ports and DIN mount pattern. Anodised aluminium body with NBR seal material. Maximum operating pressure of 8 bar and flow rate of 1050 L/min.
Compact size: 131.3mm length, 56.5mm height, and 22mm width. Operating temperature range from 5°C to 50°C. Plug connector electrical connection for secure interface. Valve function supports 5/2 monostable and bistable operations.
Manufactured in Poland ensuring high quality standards.
This pneumatic solenoid valve is ideal for applications in fluid power, industrial automation, pneumatic control systems, manufacturing, and HVAC industries. The robust construction and performance specs ensure reliable operation even in harsh industrial environments.
Explore our extensive range of pneumatic valves and components at EnvMart for industrial-grade fluid power solutions.
Explore more products in our Pneumatic Solenoid Valves category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 8 bar.
This unit has a maximum flow rate of 1050 L/min.
It operates at a voltage of 24V dc.
The dimensions of this pneumatic solenoid valve are 131.3mm in length, 56.5mm in height, and 22mm in width.
The valve body is made of anodised aluminium, and it features nitrile rubber (NBR) seals.
It operates within a temperature range of 5°C to 50°C.
It is equipped with a plug connector electrical connection.
This pneumatic solenoid valve has a 5/2 function, supporting both monostable and bistable operation modes.
This model features a total of 5 ports.
It is designed for manifold mounting and features a DIN mount pattern.
The solenoid power consumption is 1.6W.
This model is manufactured in Poland.
