Fluro M12 x 1.75 Female Stainless Steel Rod End with 12mm Bore, Metric Thread, High Dynamic Load Rating GIRSW12R

Fluro GIRSW12R Stainless Steel Rod End, featuring an M12 x 1.75 female metric thread and 12 mm bore diameter, provides exceptional performance in dynamic mechanical linkages.

Made from high-grade stainless steel, this rod end is designed to resist corrosion, making it suitable for demanding industrial environments including mechanical, fluid power, and construction applications.

The rod end supports a dynamic load rating of 34.5 kN and a static load rating of 32 kN, enabling it to handle significant stress and tension loads in rotating and linear actuation systems.

Its operational temperature range from -50°C to 250°C allows use in both cold and high-temperature processes, while the PTFE liner reduces friction and extends service life. The overall width of 66 mm and right-hand thread direction ensure compatibility with standard mechanical assemblies requiring metric connections.

This rod end is primarily used in industrial machinery and equipment, agricultural machinery, and fluid power systems where robust and reliable rotary bearing support is essential.

Constructed from durable stainless steel suitable for corrosive conditions. Female thread connection size M12 x 1.75 with right-hand thread direction. Capable of withstanding dynamic load rating of 34.5 kN and static load rating of 32 kN.

Operates reliably between temperatures of -50°C to 250°C. Equipped with a PTFE liner for reduced friction and wear resistance. Overall width dimension of 66 mm ensures sturdy mounting and fitment. Ideal for applications involving high dynamic pressure and tension loads.

Manufactured in Germany ensuring quality and precision standards. Explore Fluro Rod Ends and related rotary bearing units at EnvMart for industrial, laboratory, and manufacturing applications requiring precision mechanical components.
