Air Compressor 5hp Three Phase IR Type 30 (1242)

Name: Air Compressor 5hp Three Phase IR Type 30 (1242)
Brand: ESPL
SKU: ABSNA
Price: 747.36 USD
Availability: InStock



SKU ABSNA Category Air Compressor Brand ESPL Condition New

Specifications

Warranty	12 Months Warranty Against Manufacturing Defect
Pressure	175 psi / 12.3 bar or kg
Standard Accessories	Automatic on-off pressure Control Switch Air Delivery Valve Pressure gauge Manual water Tank Drain valve Belt Guard Inlet Air Filter & Check Valve in Discharge line Safety Valve Fly wheel (Pulley) Motor Slide Rails V Belts.
Model	Maruti 1242
Quality	Maruti Compressor
MOTOR HP	5 3phase Make Maruti
Piston Displacement	17.32
Kw	3.73 / 50hz
LPM	484.96
No of Pistons	2
m3/min	0.48
Air Tank	200 Size 18 inch x 48 inch 4mm shall 5mm disk
Item Packaging	Wooden Crate Packing
Item SKU Number	TSC5HPTP200
m3/hr	29.42

Key Features

Brand New and High Quality Industrial Air Compressor
Durable Electrical Energy into Mechanical Energy
Compatible with 20cfm Refrigerator Air Dryer

Product Description

Air Compressor 5hp Three Phase IR Type 30 (1242) During the down stroke of the piston of a two-stage compressor, the air is forced into the first stage cylinder by atmospheric pressure through an inlet filter and an intake valve in the head of the compressor. When the piston reaches the bottom of the stroke, the intake valve closes. During the upstroke of the piston, the air is compressed, the discharge valve opens and the compressed air is delivered to the second stage through finned intercooler tubes where the heat created by the compressor is allowed to dissipate. The cooled compressed air is then forced into the second-stage cylinder via an intake valve. The second-stage cylinder fills with compressed air during the down stroke of the second-stage piston. During the upstroke of that piston, the air is compressed and released through a discharge valve to the air receiver tank. In one revolution of the crankshaft, the complete two-stage cycle is completed

Covered with 1 Year Warranty
Rock-bottom Price with CE Quality Product.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The air compressor has a pressure rating of 175 psi, which is equivalent to 12.3 bar or kg.

It features a 5 horsepower motor that operates on three-phase power.

The piston displacement of this air compressor is 17.32.

The air tank has a size of 18 inches by 48 inches and is constructed with 4mm and 5mm disk thickness.

Included standard accessories are an automatic on-off pressure control switch, air delivery valve, pressure gauge, manual water tank drain valve, belt guard, inlet air filter, check valve in discharge line, safety valve, flywheel (pulley), motor slide rails, and V belts.

The air delivery capacity is 484.96 liters per minute (LPM), which translates to approximately 29.42 cubic meters per hour (m3/hr).

This model is equipped with two pistons.

The air compressor comes with a 12 months warranty against manufacturing defects.

The weight of the compressor is not specified in the provided data.

This compressor operates at 3.73 kW with a frequency of 50 Hz.

The item is packaged in a wooden crate for protection during shipping.

It is a two-stage compressor that compresses air through a piston mechanism in two stages for efficient air delivery.
