Air Compressor 3hp Single Phase IR Type 30 (1234)

Name: Air Compressor 3hp Single Phase IR Type 30 (1234)
Brand: ESPL
SKU: ABSMZ
Price: 615.84 USD
Availability: InStock



SKU ABSMZ Category Air Compressor Brand ESPL Condition New

Specifications

Warranty	12 Months Warranty Against Manufacturing Defect
Pressure	175 psi / 12.3 bar or kg
Standard Accessories	Automatic on-off pressure Control Switch Air Delivery Valve Pressure gauge Manual water Tank Drain valve Belt Guard Inlet Air Filter & Check Valve in Discharge line Safety Valve Fly wheel (Pulley) Motor Slide Rails V Belts.
Model	Maruti 1234
Quality	Maruti Compressor
MOTOR HP	3 Single Phase MARUTI MAKE
Piston Displacement	9.79
Kw	2.24/50Hz
LPM	274.12
No of Pistons	2
m3/min	0.27
Air Tank	160 LTR. Size 16 inch x 50 inch 4mm shall / 5mm disk.
Item Packaging	Wooden Crate Packing
Item SKU Number	TSC3HPSP160
m3/hr	16.63

Key Features

Brand New and High Quality Industrial Air Compressor
Durable Electrical Energy into Mechanical Energy
Compatible with 20cfm Refrigerator Air Dryer

Product Description

Air Compressor 3hp Single Phase IR Type 30 (1234) During the down stroke of the piston of a two-stage compressor, the air is forced into the first stage cylinder by atmospheric pressure through an inlet filter and an intake valve in the head of the compressor. When the piston reaches the bottom of the stroke, the intake valve closes. During the upstroke of the piston, the air is compressed, the discharge valve opens and the compressed air is delivered to the second stage through finned intercooler tubes where the heat created by the compressor is allowed to dissipate. The cooled compressed air is then forced into the second-stage cylinder via an intake valve. The second-stage cylinder fills with compressed air during the down stroke of the second-stage piston. During the upstroke of that piston, the air is compressed and released through a discharge valve to the air receiver tank. In one revolution of the crankshaft, the complete two-stage cycle is completed

Covered with 1 Year Warranty
Rock-bottom Price with CE Quality Product.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The maximum pressure of this air compressor is 175 psi, which is equivalent to 12.3 bar or kg.

The piston displacement of this model is 9.79 cubic meters per hour.

This air compressor features a 3 horsepower single-phase motor.

The air tank capacity is 160 liters, with dimensions of 16 inches by 50 inches and a thickness of 4mm to 5mm.

Standard accessories include an automatic on-off pressure control switch, air delivery valve, pressure gauge, manual water tank drain valve, belt guard, inlet air filter, check valve, safety valve, flywheel, motor slide rails, and V belts.

The air delivery rate is 274.12 liters per minute.

This compressor is equipped with two pistons.

The air compressor comes with a 12 months warranty against manufacturing defects.

The model number of this air compressor is Maruti 1234.

The weight of the air compressor is not specified in the provided information.

The dimensions of the air tank are 16 inches in diameter and 50 inches in height.

This compressor operates on a single-phase power supply with a power rating of 2.24 kW at 50Hz.
