Air Compressor 3hp Three Phase IR Type 30 (1234)
Specifications
| Warranty | 12 Months Warranty Against Manufacturing Defect |
|---|---|
| Brand | Maruti Compressor |
| Pressure | 175 psi / 12.3 bar or kg |
| Standard Accessories | Auto matic on-off pressure Control Switch Air Delivery Valve Pressure gauge Manual water Tank Drain valve Belt Guard Inlet Air Filter & Check Valve in Discharge line Safety Valve Fly wheel (Pulley) Motor Slide Rails V Belts. |
| Model | Maruti 1234 |
| MOTOR HP | 3 3phase Make Maruti |
| Piston Displacement | 9.79 |
| Kw | 2.24 / 50hz |
| LPM | 274.12 |
| No of Pistons | 2 |
| m3/min | 0.27 |
| Air Tank | 160 LTR. Size 16 inch x 50 inch 4mm shall / 5mm disk. |
| Item Packaging | Wooden Crate Packing |
| Item SKU Number | TSC3HPTP160 |
| m3/hr | 16.63 |
Key Features
- Brand New and High Quality Industrial Air Compressor
- Durable Electrical Energy into Mechanical Energy
- Compatible with 20cfm Refrigerator Air Dryer
Product Description
Air Compressor 3hp Three Phase IR Type 30 (1234) During the down stroke of the piston of a two-stage compressor, the air is forced into the first stage cylinder by atmospheric pressure through an inlet filter and an intake valve in the head of the compressor. When the piston reaches the bottom of the stroke, the intake valve closes. During the upstroke of the piston, the air is compressed, the discharge valve opens and the compressed air is delivered to the second stage through finned intercooler tubes where the heat created by the compressor is allowed to dissipate. The cooled compressed air is then forced into the second-stage cylinder via an intake valve. The second-stage cylinder fills with compressed air during the down stroke of the second-stage piston. During the upstroke of that piston, the air is compressed and released through a discharge valve to the air receiver tank. In one revolution of the crankshaft, the complete two-stage cycle is completed
- Covered with 1 Year Warranty
- Rock-bottom Price with CE Quality Product.
