Siemens 3 Phase Digital LCD Energy Meter 7KT1662, 400 V L-L, 230 V L-N, 5 A, Modbus RTU/ASCII + MID, Self-Powered 7KT1662
Specifications
| Country of Origin | Italy |
|---|---|
| Display Type | LCD |
| Brand | Siemens |
| Model | 7KT1662 |
| Depth | 63mm |
| Number of inputs | 1 |
| Series | 7KT PAC1600 |
| Maximum Operating Temperature | 55°C |
| Meter Type | Digital |
| Minimum Operating Temperature | -25°C |
| Digit height | 85mm |
| Number of Phases | 3 |
| Standards/Approvals | CE |
| Cutout Height | 90.6mm |
| Cutout Width | 72.3mm |
| SENTRON, measuring device, 7KT PAC1600, LCD, L-L | 400 V, L-N: 230 V, 5 A, strd rail instr., 3-phase, Modbus RTU/ASCII + MID, apparent/active/ reactive energy, self-powered, screw terminals |
Key Features
- Equipped with a clear LCD display for effortless reading.
- Designed for three-phase power systems supporting 400 V L-L and 230 V L-N voltages.
- Features pulse output for integration with external devices.
- Operates reliably in temperatures ranging from -25°C to 55°C.
- Compact dimensions with a cutout size of 90.6 mm height and 72.3 mm width.
- Depth of 63 mm suitable for standard rail installation.
- Self-powered with screw terminal connections ensuring secure wiring.
- CE certified, complying with European standards.
Product Description
Siemens 7KT1662 is a high-precision 3 Phase Digital LCD Energy Meter designed for industrial and commercial applications requiring reliable monitoring of electrical energy parameters. This meter is suitable for measuring apparent, active, and reactive energy within three-phase power systems, featuring an LCD display for easy and clear readings. It operates at line-to-line voltage of 400 V and line-to-neutral voltage of 230 V with a current rating of 5 A.
The device supports Modbus RTU/ASCII communication protocols, enabling integration with automation and control systems, and is MID certified for measurement accuracy compliance. The pulse output functionality allows for external metering and data acquisition uses. This Energy Meter is self-powered, thereby eliminating the need for an external power source, and includes screw terminals for reliable electrical connections.
Designed for durability, the meter performs effectively within a wide temperature range of -25°C to 55°C, and its compact profile with a 90.6 mm by 72.3 mm cutout size and 63 mm depth fits standard DIN rail installations. Siemens 7KT1662 conforms to CE standards, ensuring safety and quality for industrial usage.
This meter is ideal for energy monitoring in industrial plants, commercial buildings, process control, HVAC systems, and electrical automation environments requiring precise energy measurement capabilities.
Equipped with a clear LCD display for effortless reading. Designed for three-phase power systems supporting 400 V L-L and 230 V L-N voltages. Features pulse output for integration with external devices. Operates reliably in temperatures ranging from -25°C to 55°C.
Compact dimensions with a cutout size of 90.6 mm height and 72.3 mm width. Depth of 63 mm suitable for standard rail installation. Self-powered with screw terminal connections ensuring secure wiring. CE certified, complying with European standards.
Supports one input phase for precise measurement. Digit height of 8.5 mm enhances readability. Explore Siemens products on EnvMart for reliable industrial measuring instruments and automated control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates at a line-to-line voltage of 400 V and a line-to-neutral voltage of 230 V.
It operates reliably in temperatures ranging from -25°C to 55°C.
This unit is equipped with an LCD display for clear and easy readings.
The device is self-powered, eliminating the need for an external power source.
The cutout dimensions are 90.6 mm in height and 72.3 mm in width, with a depth of 63 mm suitable for standard rail installation.
It supports Modbus RTU/ASCII communication protocols for integration with automation and control systems.
This model measures apparent, active, and reactive energy within three-phase power systems.
The digit height is 8.5 mm, enhancing readability.
Yes, it is CE certified, complying with European standards for safety and quality.
This model supports three phases for precise energy measurement.
It includes screw terminal connections to ensure secure wiring.
It belongs to the 7KT PAC1600 series.
