SMC Pneumatic Solenoid Valve 3 Port 1/4 in G Thread VT317 Series 24V DC 6W Die Cast Aluminium Body

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Solenoid Valve 3 Port 1/4 in G Thread VT317 Series 24V DC 6W Die Cast Aluminium Body



Category Pneumatic Solenoid Valves Brand SMC Condition New

Specifications

Country of Origin	India
Voltage	24V dc
Brand	SMC
Body Material	Die Cast Aluminium
Maximum Operating Pressure	0.9 Mpa
Height	45mm
Length	89.5mm
Model	VT317
Width	30mm
Mount Type	Stand Alone
Series	VT317
Number Of Ports	3
Maximum Operating Temperature	50°C
Number of Positions	2
Port Size	1/4 in
Seal Material	Rubber
Minimum Operating Temperature	0°C
Actuation Type	Solenoid/Spring
Maximum Flow Rate	687.05NL/min
Standards/Approvals	RoHS
Connection Thread Standard	G
Minimum Pilot Pressure	0MPa
Electrical Connection Type	DIN Connector
Solenoid Type	Single
Port Gender	Female
Solenoid Power Consumption	6W

Key Features

Direct operated 3 port pneumatic solenoid valve ensuring reliable valve functions.
Rated for maximum operating pressure of 0.9 MPa and maximum flow rate of 687.05 NL/min.
Die cast aluminium body with durable rubber seals for long service life.
Operates at 24V DC with a solenoid power consumption of 6W.
Standard G type threaded 1/4 inch female ports with DIN connector electrical connection.
Suitable for ambient operating temperatures from 0°C to 50°C.
Includes push button manual override and surge voltage protection for enhanced safety.
Complies with RoHS standards for environmental compliance.

Product Description

SMC VT317 Pneumatic Solenoid Valve model EVT317V-5DO-02F-Q is a robust 3 port, direct operated pneumatic valve utilizing solenoid and spring return actuation. Designed with a die cast aluminium body and rubber seals, the valve delivers reliable performance in pneumatic control applications commonly found in industrial automation, manufacturing, and fluid power systems.

The valve features G standard tapered female threads with 1/4 inch port sizing, supporting a maximum operating pressure of 0.9 MPa and a maximum flow rate of 687.05 NL/min, making it suitable for controlled air flow in pneumatic circuits. It operates from a 24V DC power supply, drawing 6W from the solenoid coil, protected by surge voltage suppression circuits and equipped with a DIN connector for electrical interface.

Compact and lightweight, the valve measures 89.5 mm in length, 45 mm in height, and 30 mm in width, allowing installation in confined spaces. The valve supports manual override operation via a push button, providing control flexibility during maintenance or setup.

The VT317 series has 2 positions, enabling precise flow direction control through its 3 ports. Operating temperature range of 0°C to 50°C enables deployment in typical industrial environments without performance degradation. As a RoHS compliant product, it meets environmental standards for hazardous substance reduction.

Direct operated 3 port pneumatic solenoid valve ensuring reliable valve functions. Die cast aluminium body with rubber sealing for durability. Operates at 24V DC with 6W solenoid consumption and surge voltage protection.

Manual push button override for operational flexibility. Compact dimensions facilitate versatile mounting in pneumatic systems. Maximum operating pressure of 0.9 MPa and flow rate of 687.05 NL/min. Standard G 1/4 inch female ports with DIN electrical connector interface.

Complies with RoHS environmental standards.

This pneumatic solenoid valve is ideal for use in industrial automation, fluid power control, and pneumatic machinery in sectors such as manufacturing, packaging, automotive assembly, and HVAC systems.
