IKO Nippon Thompson Needle Roller Bearing 12 mm ID, 24 mm OD, 16 mm Width, Open End Type TAFI122416

IKO Nippon Thompson TAFI122416 is a precision needle roller bearing featuring a 12 mm inside diameter, 24 mm outside diameter, and 16 mm race width. This bearing is designed for use in demanding mechanical applications requiring high load capacity and space-saving design.

The bearing incorporates a parallel bore and an open end type, allowing it to be used with or without an inner ring depending on shaft finish and hardness, providing installation flexibility.

This bearing offers a static load rating of 15.1 kN and a dynamic load rating of 12.3 kN, making it suitable for high-load rotating machinery components. It can operate at speeds up to 25000 rpm with oil lubrication and 15000 rpm with grease, ensuring reliable performance under varying lubrication conditions.

Manufactured in Japan, this TAF series bearing is ideal for industrial, mechanical, HVAC, manufacturing, and other heavy-duty applications. Its compact size and high load carrying capability contribute to efficient machine design and operation.

This needle roller bearing features a 16 mm race width for optimal performance. The bearing has a parallel bore type and an open end design. It supports a static load rating of 15.1 kN and a dynamic load rating of 12.3 kN.

Maximum operating speeds are 25000 rpm with oil lubrication and 15000 rpm with grease. The bearing is part of the TAF series and manufactured in Japan. Designed for space-saving applications with inner ring compatibility depending on shaft finish and hardness.

High load carrying capacity suitable for rotary bearing uses in mechanical and industrial machinery. Explore the wide range of Roller Bearings and rotary bearing units available at EnvMart for comprehensive industrial equipment solutions.
