INA Yoke Cam Follower 45mm Bore Diameter, 90mm Roller Diameter, 23.7kN Dynamic Load Rating LR209-2RS
Specifications
| Country of Origin | India |
|---|---|
| Brand | INA |
| Model | LR209-2RS |
| Sub Type | Yoke |
| Roller Diameter | 90mm |
| Bore Diameter | 45mm |
| Static Load Rating | 13.7kN |
| Dynamic Load Rating | 23.7kN |
Key Features
- Designed with a yoke sub type suitable for mounting on shafts or studs.
- Robust roller diameter of 90mm ensures durability under high radial loads.
- Static load rating of 13.7kN and dynamic load rating of 23.7kN for heavy-duty usage.
- Features thick-walled outer rings with crowned outside surface for optimal load support.
- Sealed on both sides to protect bearings from contaminants and extend service life.
- Enables tolerance to axial loads from misalignment or temporary impacts.
- Suitable for industrial, mechanical, and manufacturing applications requiring precise motion control.
Product Description
INA LR209-2RS Yoke Cam Follower is specialized bearing designed with a 45mm bore diameter and 90mm roller diameter. It supports significant radial loads with its dynamic load rating of 23.7kN and static load rating of 13.7kN, crafted with a robust yoke type sub design for mounting flexibility.
This cam follower includes thick-walled outer rings with a crowned surface, enabling it to tolerate axial loads caused by minor misalignments or skewed running. It is sealed on both sides, protecting internal components from dust and moisture, thereby extending operational reliability.
Its construction allows it to run smoothly on a flat mating track rather than in a housing bore. This design can accommodate eccentric collar adjustments, allowing for larger manufacturing tolerances in adjacent constructions.
The cam follower is ideal for a wide range of industrial uses such as mechanical machinery, manufacturing automation, material handling, and fluid power systems. Its capability to handle heavy loads with high precision makes it suitable for demanding environments.
These cam followers are ready-to-fit, featuring needle or cylindrical roller bearings with either single or double-row designs for optimal performance. Their yoke configuration aids in simple mounting on shafts or studs, ensuring ease of integration across mechanical assemblies.
Robust construction with thick-walled outer rings and crowned surfaces. High dynamic and static load ratings for demanding applications. Sealed design protects against contamination and extends service life. Accommodates axial loads from slight misalignments or shock impacts.
Adjustable to mating track via eccentric collar for flexible installation. Suitable for industrial machinery, manufacturing, and fluid power applications. Explore the INA range of precision Cam Followers and roller bearings at EnvMart for high-quality solutions designed for mechanical and fluid power engineering projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The dynamic load rating of the INA LR209-2RS cam follower is 23.7kN.
This cam follower has a bore diameter of 45mm.
It is suitable for industrial machinery, manufacturing automation, material handling, and fluid power systems.
It is designed with thick-walled outer rings and a crowned surface, allowing it to tolerate axial loads caused by minor misalignments or shock impacts.
The static load rating of the INA LR209-2RS is 13.7kN.
It features a yoke type design, which allows for mounting on shafts or studs.
The roller diameter of this cam follower is 90mm.
The specific materials are not detailed, but it includes thick-walled outer rings designed for durability under high radial loads.
The cam follower is sealed on both sides to protect internal components from dust and moisture, which helps extend its operational reliability.
Yes, this cam follower is ready-to-fit and features needle or cylindrical roller bearings for optimal performance.
Yes, it can accommodate eccentric collar adjustments, allowing for larger manufacturing tolerances in adjacent constructions.
The country of origin for this cam follower is India.
