EMERSON ? AVENTICS Pneumatic Solenoid/Pilot-Operated Control Valve, Electro Pneumatic Control, 24V dc, 7 bar, 180 R422103583

EMERSON ? AVENTICS model R422103583 is a pneumatic solenoid and pilot-operated control valve designed for electro pneumatic control applications. It operates at 24V dc and is rated for a maximum operating pressure of 7 bar with a maximum flow rate of 180 L/min. This valve is engineered for industrial pneumatic systems requiring reliable and precise air control.

The body material is polyoxymethylene, which provides robustness suitable for industrial environments. Rubber seals ensure leak-tightness and longevity. The valve features a single solenoid and air actuation method, equipped with an internal pilot and a manual override with detent function for enhanced user control.

Designed with M3 metric port size, female gender ports, and a screw mount type, this valve offers easy installation and compatibility with standard pneumatic components. Its electrical connection uses a plug with an M8 3-pin layout, consuming only 1.3W of power, optimizing energy efficiency.

Operational temperature range extends from -10°C to 50°C, making it suitable for varied industrial environments. The compact dimensions - 82.1mm length, 53mm height, and 10.8mm width - allow for integration within space-constrained setups.

Compliant with EN/IEC standards, this valve ensures quality and industry-accepted safety. With a valve function dedicated to electro pneumatic control and a two-position operation, this versatile component serves in applications across manufacturing, automation, fluid power systems, and process controls.

Operates with a single solenoid and air actuation for precise control. Constructed with polyoxymethylene body material and rubber seals for durability. Compatible with metric thread standard and M3 port size with female ports.

Maximum flow rate of 180 L/min suitable for efficient pneumatic systems. Features screw mount type and internal pilot with manual override detent for operational flexibility. Supports operating temperature range from -10°C to 50°C.

Equipped with M8 3-pin plug electrical connection and low power consumption of 1.3W. Measures 82.1mm length, 53mm height, and 10.8mm width, compact for integration. Complies with EN/IEC standards assuring quality and safety.

This pneumatic solenoid valve model R422103583 by EMERSON ? AVENTICS is ideal for industrial, manufacturing, automation, and HVAC pneumatic control applications. It offers reliable performance with its high pressure and flow capacity and versatile mounting and connection options. Explore more pneumatic valves and electro pneumatic control components at EnvMart.
