Cartridge Seals B91/CG Series
Specifications
| Pressure | 5 to 35 Bar (kg/cm 2) |
|---|---|
| Temperature | -20 C to 300 C |
| Shaft Diameter | 18 mm To 100 mm |
| Shaft Speed | Upto 4000 RPM According to Shaft Size & Pressure. |
| Hardware | SS 316 Hast - C Monel Alloy - 20 |
| Face Material | (Dynamic Ring & Stationary Ring) Carbon Ceramic (99.5%) Silicon Carbide. Tungsten Carbide Chrome Cast - Steel & Which Are Suitable For Fluid |
| Secondary Seal | Viton EPDM Silicon Aflas PTEF GFT TCV & FEP Kalrez |
Key Features
- Easy to install
- easy to remove
- Firm grip
Product Description
Cartridge Seals B91/CG Series we are tagged as the top manufacturer and supplier of quality cartridge seals. We offer cartridge seals for any industrial application.We are tagged as the major manufacturer, supplier and exporter of high-quality cartridge seals, made of the best quality raw material. It is highly demanded in many industries.We manufacture and export the high quality cartridge seals. We are a major supplier of the mechanical seals like cartridge seals. We have designed and developed the series of B91/CG and B901/CG of the cartridge seals. It is specially designed for the various applications of the industries like chemical and petrochemical. The cartridge seals have its vast usage for syrup, water, oil, slurries, sludges and other chemicals at low and high pressure pumps. We have developed the single and double arrangement to suit the application.Application Sludge & Syrup Pump Slurry Pump Chemical Petrochemical & Refinery Pulp & Paper Boiler Feed Water Pumps Oil Pipeline Pumps Clinker Grinders.Seal Characteristics Balanced Single Acting Independent Of Direction of Rotation. Sturdy Drive Mechanism Stationary Multiple Springs.
- Low maintenance
- Sturdy construction
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pressure range for these cartridge seals is from 5 to 35 Bar (kg/cm²).
These seals can operate within a temperature range of -20°C to 300°C.
The maximum shaft speed is up to 4000 RPM, depending on the shaft size and pressure.
The hardware is made from SS 316, Hastelloy C, and Monel Alloy 20.
The face materials include Carbon Ceramic (99.5%), Silicon Carbide, Tungsten Carbide, and Chrome Cast Steel, suitable for various fluids.
The secondary seals can be made from Viton, EPDM, Silicon, Aflas, PTFE, GFT, TCV, FEP, and Kalrez.
These seals feature a balanced single acting design that is independent of the direction of rotation, along with a sturdy drive mechanism and stationary multiple springs.
The B91/CG series cartridge seals are designed for low maintenance needs.
The cartridge seals are developed in both single and double arrangements to suit various applications.
The seals are designed with sturdy construction to ensure effective performance in industrial applications.
