Vibrator Screen

The vibrating screen use excellent vibrant motor as power source, so that the materials can be thrown up on the sieve and forward to make a straight movement. It can be equipped with single or multi-screen to achieve the grading, removing impurity, removing dust, testing, washing selecting, dehydration etc. Applied FieldIt is widely used in grinding materials, chemical, construction, chemicals, pharmacy, metallurgy, ceramics, fertilizers, coal industry to screening and grading the granular and powder bulk materials.PrincipleTwo vibration motors installed on the equipment which work in simultaneously and reverse rotation. The screen box supported by the four springs produce reciprocating linear motion under the vibration force generated by the motors. When the the vertical component of the vibration acceleration N is greater than acceleration due to gravity g, material in the tank was thrown up, press forward to jump along parabolic path. Each vibration of the tank, the material would be thrown up once. In the process of encounter with the screen, the material which is smaller than screen mesh can go through it, so as to achieve classification purpose.Our range includesCircular motion vibrating screensLinear motion vibrating screensSizes available :Widths ranging from: 600 mm to 2500 mmLengths ranging from:1500 mm to 8000 mmNumber of Decks :up to 4Production Capacity = 0.5 200 Ton/Hr. (According to Requirement of client)Out Put Size =up to 100 Mesh DownPower depend upon production of materialWe design plant according to requirement of consumer.

• Simple and rational tension mode of screen, easy to replace.
• The screen frame may be replaced as per different mesh numbers, saving running cost.
