Roller Crusher For Industrial Purpose

Name: Roller Crusher For Industrial Purpose
Brand: ESPL
SKU: ABDIZ
Price: 11.59 USD
Availability: InStock



SKU ABDIZ Category Crushers Brand ESPL Condition New

Specifications

Power	depend upon production of Material
Production Capacity	0.5 10 Ton/Hr. (According to Requirement of client)
Out Put Size	10-100 Mesh (D97%) Passing

Key Features

We design plant according to requirement of consumer.
High throughput capacity
A variety of roll tooth profiles available

Product Description

Roller Crusher For Industrial Purpose A roll crusher crushes using compression, with two rolls rotating about a shaft, towards the gap between the rolls. The gap between the rolls is set to the size of the product desired, with the realization that the largest feed particle can only be 4 times the gap dimension. The particles are drawn into the gap between the rolls by their rotating motion and a friction angle formed between the rolls and the particle, called the nip angle. The two rolls force the particle between their rotating surface into the ever smaller gap area, and it fractures from the compressive forces presented by the rotating rolls. Some major advantages of roll crushers are they give a very fine product size distribution and they produce very little dust or fines. Rolls crushers are effectively used in minerals crushing. Usually, these crushers will have teeth or Smooth forms on the face of the roll. Roll crushers used for minerals and metal ores have smooth faced rolls.

Adjustable for change in product sizing
Automatic tramp relief
Low cost per ton operation

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The production capacity of this model ranges from 0.5 to 10 tons per hour, depending on the client's requirements.

The output size of the crushed material can range from 10 to 100 mesh, with 97% passing at D97%.

It operates using compression, with two rolls rotating about a shaft, drawing particles into the gap between the rolls where they are crushed by compressive forces.

A variety of roll tooth profiles are available, allowing customization according to the specific requirements of the consumer.

Yes, this model includes an automatic tramp relief feature to handle uncrushable materials.

This roller crusher is effectively used for crushing minerals and metal ores, providing a fine product size distribution.

The nip angle is the friction angle formed between the rolls and the particle, which helps draw particles into the crushing gap.

Some advantages include a fine product size distribution and minimal dust or fines produced during crushing.

The largest feed particle can only be four times the gap dimension set between the rolls.

Yes, the design of the plant can be customized according to the specific requirements of the consumer.

The gap between the rolls is crucial as it determines the size of the product desired, affecting the crushing process and output size.
