OPTIBELT Timing Belt Pulley Aluminium 9.5 mm Belt Width 5 mm Pitch 22 Teeth 22 XL 037

OPTIBELT 22 XL 037 Timing Belt Pulley is made from high-quality aluminium and tailored specifically for engineering applications requiring precise power transmission. It supports a 9.5 mm belt width with a 5 mm pitch and 22 teeth, making it suitable for force-locking or form-fit connections in various industrial drives.

The aluminium construction provides an excellent balance of strength and lightweight properties, enhancing the longevity and efficiency of belt drive systems in machinery and manufacturing processes.

The flanged pulley design ensures enhanced belt retention and alignment, reducing slippage and wear during operation.

The timing belt pulley features a pitch circle diameter of 35.57 mm, flange diameter of 41 mm, bore diameter of 19 mm, and outside diameter of 35.05 mm, enabling compatibility with standard belt profiles and shafts.

The pulley is RoHS compliant, meeting essential environmental and safety standards required in many industrial sectors. Constructed from durable aluminium for robust performance. Includes 22 teeth for precise timing and force-locking connections.

Acceptable belt width is 9.5 mm ensuring compatibility with various belts. Flanged design enhances belt alignment and stability during operation. Pitch circle diameter measures 35.57 mm for accurate fitment. Bore diameter is 19 mm to match corresponding shafts securely.

Outside diameter size is 35.05 mm optimizing pulley size efficiency. RoHS compliant ensuring environmental and safety standards.

This timing belt pulley is widely used in mechanical power transmission systems across industrial, manufacturing, and material handling applications, providing reliable and efficient operation in automated and mechanical drives.
