Brannan 100 mm G 3/8 Type G Pressure Gauge 2.5 bar 34/652/0

Brannan 34/652/0 Pressure Gauge is a high-precision measuring instrument featuring a 100 mm dial size and G 3/8 Type G brass pressure connection. Designed for industrial and fluid power uses, it measures pressures up to 2.5 bar with reliability and durability.

The gauge case is made from steel with an acrylic window, ensuring both protection and clear readability. The internal Bourdon tube is composed of phosphor bronze, paired with a brass movement mechanism for enhanced accuracy. It is suited for bottom entry installation with a 3/8 inch BSP connection size.

The design includes a loose red pointer that can be manually set to indicate normal operating pressure, aiding users in monitoring system conditions efficiently. A safety blow out disc is included to prevent damage under excessive pressure.

Operating up to a maximum temperature of 60°C, this pressure gauge complies with BS EN837-1:1998 standards, assuring quality and performance. It is intended for use on sealed or pumped systems common in pneumatic and hydraulic industrial environments.

This pressure gauge features a robust steel case with an acrylic window for clear visibility. It uses a phosphor bronze Bourdon tube element and brass movement for accuracy. The gauge is designed for bottom entry with a 3/8 inch BSP connection size.

Includes a loose red pointer to mark normal operating pressure and a safety blow out disc for protection. Operates at a maximum temperature of 60°C and complies with BS EN837-1:1998 standards. Suitable for sealed (pumped) systems in industrial and fluid power applications.

This Brannan pressure gauge is an ideal choice for applications requiring precise pressure measurement and durability in industrial, laboratory, pneumatic, hydraulic, and fluid power settings. Explore the EnvMart catalog for more measuring instruments from leading manufacturers.
