Eurotherm Panel PID Controller 1 Input 3 Relay Logic SSR 230V EPC3008

Free Delivery in India | Lowest Global Shipping Charges

Eurotherm Panel PID Controller 1 Input 3 Relay Logic SSR 230V EPC3008

Name: Eurotherm Panel PID Controller 1 Input 3 Relay Logic SSR 230V EPC3008
Brand: Eurotherm
SKU: 114967
Price: 1084.09 USD
Availability: InStock



Category Process Controllers Brand Eurotherm Condition New

Specifications

Country of Origin	Poland
Display Type	LCD
Brand	Eurotherm
Length	101mm
Model	EPC3008
IP Rating	IP65
Width	48mm
Mount Type	Panel
Number of inputs	1
Output type	3 Relay, Logic/SSR
Series	EPC3008
Input Type	Current, Thermocouple, Voltage
Maximum Operating Temperature	55°C
Control Type	PID Controller
Minimum Operating Temperature	0°C
Interfaces	Ethernet with RJ45 connector for IIoT and Industry 4
Terminal type	Screw
Standards/Approvals	RoHS
Maximum Supply Voltage	230V
Panel Depth	90mm

Key Features

Supports a single input with current, thermocouple, or voltage signal types.
Equipped with 3 relay and logic/SSR outputs for flexible control configurations.
Operates reliably within a temperature range of 0°C to 55°C.
Features a clear LCD display for easy monitoring and adjustment.
Screw terminal connections ensure secure and straightforward installation.
Panel mount type with IP65 rating for dust and splash protection.
Designed with native Ethernet communication for Industry 4.0 and Industrial IoT integration.
Complies with RoHS standards and is manufactured in Poland.

Product Description

Eurotherm EPC3008 is a panel-mounted programmable single loop PID controller designed for precise and repeatable process control in thermal and other processing industries. It features a single input capable of accepting current, thermocouple, or voltage signals, and outputs through 3 relays with logic and SSR capability at 230V supply voltage. The controller operates effectively within a temperature range from 0°C to 55°C, making it suitable for various industrial environments.

This controller incorporates an LCD display for user-friendly interaction and enhanced monitoring. The screw terminal connections facilitate robust and secure wiring, while the panel mount style with an IP65 rating provides resistance against dust and water ingress, ideal for industrial conditions.

The Eurotherm EPC3008 supports advanced functionality with built-in Ethernet and compatibility with modbus, Ethernet/IP, and BACnet protocols, enabling seamless integration into Industry 4.0 and Industrial Internet of Things (IIoT) environments. Its compact dimensions (101mm length, 48mm width, and a panel depth of 90mm) allow versatile installation in control panels.

Designed and manufactured in Poland, the EPC3008 meets RoHS compliance ensuring environmental safety. Its enhanced PID control algorithm with a fast cutback function ensures minimal overshoot and rapid system response, meeting stringent aerospace regulatory accuracy standards.

Typical applications include process optimization in manufacturing, HVAC systems, water treatment, and laboratory instrumentation requiring precise temperature or process parameter control. The native Ethernet connectivity ensures the controller is ready for digital communication networks used in modern industrial automation setups.

Supports a single versatile input type including current, thermocouple, and voltage. Provides multiple relay outputs to drive heating or other control elements. High IP rating for protection against challenging industrial environments.

Ethernet connectivity for easy integration with Industry 4.0 systems. Compact panel mount design suitable for space-constrained control panels. Complies with environmental and safety standards including RoHS. Manufactured to meet high-quality standards in Poland.

Explore EnvMart's comprehensive range of temperature and Process Controllers by Eurotherm to enhance industrial automation, manufacturing precision, and system reliability.
