FAG Self-Aligning 2 Row Ball Bearing, 45 mm Inside Diameter, 100 mm Outside Diameter, 25 mm Race Width, Polyamide 1309-TVH

FAG 1309-TVH is a high-quality self-aligning 2 row ball bearing designed with 45 mm inside diameter, 100 mm outside diameter, and a 25 mm race width. This bearing uses a polyamide cage and steel balls to provide excellent durability and reliability in harsh industrial environments.

The bearing is engineered to compensate for angular misalignments between the outer and inner rings, making it ideal for applications involving high radial loads. It delivers quieter operation and lower temperatures even at high speeds because of its point contact design in comparison to barrel roller bearings with line contact.

This model features an open end type which facilitates easy maintenance and lubrication, enhancing the bearing’s service life. It is suitable for a wide range of industrial machinery requiring stable and reliable rotating components.

With a static load rating of 12.7 kN and dynamic load rating of 38.5 kN, the FAG 1309-TVH offers strong load support. Its internal clearance is rated CN, optimizing performance precision. The bearing is rated to operate safely up to speeds of 7500 rpm, supporting demanding operational speeds.

Inside diameter of 45 mm and outside diameter of 100 mm for standard compatibility. Polyamide cage for enhanced resilience and reduced friction. Steel balls designed for high durability and wear resistance. Race width of 25 mm supporting structural robustness.

Open end type for ease of servicing. Static and dynamic load ratings suitable for high-load industrial use. Self-aligning feature compensates for angular misalignment in assemblies. Quiet and low temperature operation at high rotational speeds.

Precision CN internal clearance for optimal function.

This bearing is widely used in mechanical machinery, manufacturing equipment, conveyor systems, and other industrial tools requiring reliable rotary bearing units. Its robust construction and high-speed capabilities make it suitable for applications in sectors including industrial, manufacturing, and fluid power systems.
