LDK M10 Female 304 Stainless Steel Rod End, 10mm Bore Metric SPHS10EC x 1.25
Specifications
| Country of Origin | China |
|---|---|
| Brand | LDK |
| Material | 304 Stainless Steel |
| Model | SPHS10EC x 1.25 |
| Body | 304 Stainless steel |
| BALL | 440C Stainless Steel, heat treated, HRC56 min Precision ground, polished |
| Overall Width | 56mm |
| Outside diameter | 26mm |
| Connection Size | M10 Female |
| Bore Diameter | 10mm |
| Thread Standard | Metric |
| Static Load Rating | 17.3kN |
| Dynamic Load Rating | 10.4kN |
| Race | PTFE composite |
| Sliding contact surfaces | Steel/PTFE composite |
Key Features
- Constructed with 304 stainless steel body and 440C stainless steel ball for corrosion resistance.
- Features PTFE composite race and steel/PTFE composite sliding contact surfaces for smooth operation.
- Metric thread standard ensures compatibility in metric mechanical assemblies.
- Dynamic load rating of 10.4kN and static load rating of 17.3kN supports heavy-duty uses.
- Outside diameter measures 26mm with an overall width of 56mm for precise fitting.
- Suitable for industrial, mechanical power transmission, and fluid power applications.
- Manufactured to precision with heat treated and polished ball for extended service life.
Product Description
LDK SPHS10EC x 1.25 Rod End Bearing M10 Female in 304 Stainless Steel with a 10mm Bore offers robust performance for industrial and mechanical applications. The component is designed for high durability and corrosion resistance with a heat treated 440C stainless steel ball, achieving HRC56 minimum hardness for wear resistance and precision.
The rod end includes a PTFE composite race and steel/PTFE composite sliding contact surfaces which provide low friction and enhanced smooth rotation under load. The metric thread standard and 10.4kN dynamic load rating alongside a 17.3kN static load rating ensure suitability for demanding load-bearing mechanical power transmission needs.
The rod end features an outer diameter of 26mm and an overall width of 56mm, sized for precise installation in assemblies requiring M10 female connection size. This bearing is ideal for use in hydraulic, pneumatic, industrial machinery, construction equipment, and fluid power systems where reliable rotary bearing performance is critical.
Constructed with corrosion-resistant 304 stainless steel body. Heat treated 440C stainless steel ball for durability and precision. PTFE composite race and steel/PTFE sliding surfaces for minimal friction. Dynamic load rating 10.4kN, static load rating 17.3kN for heavy-duty use.
Metric thread standard with M10 female connection and 10mm bore. Outer diameter 26mm and overall width 56mm for exact fitment. Applications include industrial machinery, mechanical power transmission, and fluid power.
Country of origin is China. Each Rod End Bearing is new and engineered to meet high industrial standards. Explore more precision rod ends and mechanical bearings in this category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The dynamic load rating of this rod end bearing is 10.4kN.
It is constructed with a 304 stainless steel body and features a heat-treated 440C stainless steel ball.
The static load rating for this rod end is 17.3kN.
The outer diameter is 26mm and the overall width is 56mm.
The bore diameter of this rod end bearing is 10mm.
Yes, this rod end bearing is designed with a metric thread standard, specifically an M10 female connection size.
It features steel/PTFE composite sliding contact surfaces for smooth operation.
This rod end is suitable for industrial machinery, mechanical power transmission, and fluid power applications.
The country of origin for this rod end bearing is China.
It has a PTFE composite race, which contributes to its low friction characteristics.
The ball is heat treated to achieve a minimum hardness of HRC56 for wear resistance.
It is engineered with a heat-treated ball and polished surfaces to enhance durability and performance.
